Basics
Three.JS is build on top of WebGL. You can download the examples from the Three.JS site here Github Examples
We create out of the single elements groups.
We have the Scene which holds all the information about the actual experience and the objects in a hierarchal way.
The Camera views the scene and tells the renderer what we looking at.
The Renderer responsible to give the user the images we want to see.
Hierarchal structure of scene
We have a parent-child relationship in our scene and between the meshes. Children of a parent will inherit properties from the parent mesh. So if we group elements the children of the group will be transformed relatively from the parents values.
Setup
To install three js in your project npm install three
To import the entire t3js library to our file
import * as THREE from 'three'
Add a Scene
The scene is like a container for objects, lights and particles etc.
In THREE.JS you can have one or multiple scenes. You add the meshes that you create to the Scenes you want.
Add a Mesh
A mesh is composed out of geometry(shape) and a material(surface color). We need to add both to the Mesh object. We then add the
mesh to the scene.
const cubeGeo = new THREE.BoxGeometry(1, 1, 1);
//We pass an object into the material containing all the options for that material
const cubeMaterial = new THREE.MeshBasicMaterial({ color: "red" });
const cubeMesh = new THREE.Mesh(cubeGeo, cubeMat);
scene.add(cubeMesh);
Create a group
By changing the transformations of the group we apply it to all the children of the group.
Add a Camera
To see the elements in our scene we need to add a Camera
const camera = new THREE.PerspectiveCamera(
fieldOfView,
aspectRatio,/*window.innerWidth/window.innerHeight,*/
near /* everything closer thant this you wont see */
further /*anything further than this you wont see*/
);
const camera = new THREE.PerspectiveCamera(
75,
window.innerWidth/window.innerHeight,
0.1,
30
)
// We need to move the camera back otherwise camera and object are both at (0,0,0)
camera.position.z = 5;
scene.add(camera);
We need to pass a canvas html element to our website that shows our Three.JS scene.
canvas class="canvasClass"></canvas>
In the JS file we then grab that element and reference it to the renderer because it takes the canvas as an object as input.
const canvas = document.querySelector('canvas.canvasClass)
Add renderer
The renderer renders the scene from the camera point of view and draws it onto a canvas.
We need to specify the canvas property corresponding to the HTML <canvas> element that we add to the page.
For that we can usedocument.querySelector(...)
//Because we gonna use the canvas often for multiple operations it makes sense to assign it to a variablle
const canvas = document.querySelector('canvasClassName')
const renderer = new THREE.WebGLRenderer({
canvas:canvas
})
//To specify how big it should be rendered
renderer.setSize(window.innerWidth,window.innerHeight)
renderer.render(scene,camera);
If we would just call renderer.render(...) it would just render the scene one time.
In order to render the scene on every frame we create a function that executes at the speed of the browsers framerate. We then call the renderer in that function. At the end we need to call the function one time so it goes into the loop.
function animate() => {
renderer.render(scene,camera);
window.requestAnimationFrame(animate)
}
animate();
So anytime we want to make changes to the scene we need to set it before we call the animate loop because renderer basically takes a snapshot of the current scene and shows it for that frame.
Change background of Scene
We can change the background of our scene with
scene.background = new THREE.Color(0xffffff)
Make the Background of our Scene transparent / Fox elastic scroll
To make the background of our scene not black but transparent
we can set alpha:true in the renderer
or you can use the .setClearColor() method to set a specific color or .setClearAlpha(0)
for the clear Alpha.
Resizing Scene/Canvas depending on screen size
To make the canvas fit our viewport we use window.innerWidth/.innerHeight
We also need to get rid of the default margins of the browsers
To fix the canvas at the top
.canvas {
position: fixed;
top: 0;
left: 0;
outline: none; /*blue outline when drag and dropping*/
}
To remove any kind of scrolling we can use
To handle resizing the canvas we need to know when the window gets resized.
For that we listen to the resize event of the window.
window.addEventListener("resize", () => {})
When we do changes to the camera and the camera.aspect we need to call camera.updateProjectionMatrix().
//(eventName, callback function)
window.addEventListener('resize', () => {
camera.aspect = window.innerWidth/window.innerHeight;
camera.updateProjectionMatrix();
renderer.setSize(window.innerWidth/window.innerHeight);
})
Handling pixel ratio
Because different devices can have different pixel ratios we should
adapt the pixelRatio of the renderer to the pixel ratio to the
screen of our device.
To avoid performance issues on devices with higher pixel ratios we
set the maximum pixel ratio to 2 with the Math.min().
renderer.setPixelRatio(Math.min(window.devicePixelRatio,2))
We add this to the window.addEventListener("resize",()=>{})
Fullscreen
You first need to decide what interaction will trigger the fullscreen. You could use a HTML button or a double click for example. To toggle between fullscreen and no fullscreen every time we execute the action we check if window is already in fullscreen. The fullscreen method is linked with the html-element. So we need to define which element we want to show in fullscreen.
window.addEventListener("dblclick",()=> {
if(!document.fullscreenElement){
canvas.requestFullscreen()
} else {
document.exitFullscreen()
}
})
To make sure this also works in other browser like Safari
we need to extend this with document.webkitFullscreen
window.addEventListener("dblclick",()=>{
const fullscreenElement = document.fullscreenElement || document.webkitFullscreenElement
if(!fullscreenElement){
if(canvas.requestFullscreen){
canvas.requestFullscreen()
} else if(canvas.webkitRequestFullscreen){
canvas.webkitRequestFullscreen();
}
} else {
if(document.exitFullscreen){
document.exitFullscreen();
} else if(document.webkitExitFullscreen){
document.webkitExitFullscreen();
}
}
})
Antialiasing
Get the device pixel ration we can use
window.devicePixelRatio
Set the pixel ration
renderer.setPixelRatio(window.devicePixelRatio)
Because of different devices and ultra high pixel ratios we want to limit the max pixel ratio so the code stays performant
Add antialisaing to renderer
Transforming Objects
When we set the different parameters and transformations to our meshes we set the local rotation, scale, and transform.
All classes that inherit from the Object3D class possess position, scale, rotate, quaternion properties.
All these properties will internally be compiled to Matrices by Three.JS.
To see the axes in our scene
red = x green = y blue = z
Set Positions
To set the position we can set the single axes
cubeMesh.position.x = 1 //x right,left
cubeMesh.position.z = 1 // backward/forward
cueMesh.position.y = 1 // up and down
The unity of 1 is up to you. It can be 1 centimeter, 1 meter or even 1 kilometer. It makes sense to adapt the unit to the size of what you want to build.
We also can use a Vector3
or even copy a vector to set the position
Set Scale
To set scale of single axis
cubeMesh.scale.y = 2
or use .set() to set all three values at once
cubeMesh.scale.set(1,2,3)
or
group.scale.setScalar(2)
Set Rotation
There are two ways of handling rotations in Three.JS. You can use the rotation properties, which are expressed in Euler angles in radians.
To create like half a rotation you can use Math.PI.
const a = new THREE.Euler(0,1,1.57, 'XYZ');
//Convert Vector 3 to euler
const b = new THREE.Vector3(1,0,1);
b.applyEuler(a);
Rotate 90°
cubeMesh.rotation.y = Math.PI/2
There is also a Three.JS utility we can use to convert radians to degree
cubeMesh.rotation.y = THREE.MathUtils.degToRad(45)
We also can use the .quaternion to set the rotation of an element. It is another way to express rotation.
Three.JS by default will always apply the rotation by the order XYZ even when in the code the Y rotation comes before the x rotation.
If you want to change the order how it applies the rotation we can use
cubeMesh.rotation.reorder('YXZ'). this needs to be called before we are calling the rotations
Look at object
The .lookAt(new THREE.Vector3(0,-1,0)) method allows us to let an object look at a certain point,object or position. The object will automatically rote its -z axis towards the target.
Animations
We want to execute a function that moves the objects and renders each frame regardless of the frame rate.
For that we can use the JS function window.requestAnimationFrame().
It executes the function you provide it on the next frame.
To get reference of the time we can initialize a clock.
const clock = new THREE.Clock()
With clock.getElapsedTime() we get the difference between when the method got called and when we first initialized the clock.
Get delta time
const clock = new THREE.Clock();
let previousTime = 0;
const renderLoop = () => {
const currentTime = clock.getElapsedTime();
const delta = currentTime - previousTime;
previousTime = currentTime;
}
let time = Date.now()
const renderLoop = () => {
const currentTime = Date.now()
const deltaTime = currentTime-time;
time = currentTime;
mesh.rotation.y += 0.01 *deltaTime
}
With that delta we can create experiences that are independent of the speed of your device.
const clock = new THREE.Clock();
let previousTime = 0;
const renderLoop = () => {
let currenTime = clock.getElapsedTime();
const delta = currentTime-previousTime;
previousTime = currenTime;
cubeMesh.rotation.y += THREE.MathUtils.degToRad(1) * delta * 20;
renderer.render(scene,camera);
window.requestAnimationFrame(renderLoop)
}
renderLoop()
Rotate object in circle
const time = new THREE.Clock();
const renderLoop = () => {
const elapsedTime = time.getElapsedTime();
mesh.position.x = Math.cos(elapsedTime);
mesh.position.y = Math.sin(elapsedTime);
}
renderLoop();
Let object/camera follow path
const points = [
new THREE.Vector3(1,0,2),
new THREE.Vector3(0,0,2),
new THREE.Vector3(1,0,3),
new THREE.Vector3(1,2,2),
]
//To close the path add true as second parameter to function
const path = new THREE.CatmullRowCurve3(points);
const animate = () => {
const time = Date.now()
const t = (time/2000%6) /6;
const position = path.getPointAt(t);
cam.position.copy(position)
renderer.render()
requestAnimationFrame();
}
To orient the object we need the normalised tanged vector of the position.
It gets interesting to use mouseScroll to move the animation.
Animate with a Library
To get specific animations it can make sense to use specific JS animation libraries like GSAP
GSAP
To add GSAP we need to at it to our project
npm install --save gsap@latest
import gsap from 'gsap'
In GSAP we can create a Tween which is an animation from A to B
with gsap.to(...)
Because GSAP has a built-in requestAnimationFrame you don't need to update the animation.
gsap.to(mesh.position,{duration:1,delay:1,x:2})
const renderLoop = () => {
renderer.render(scene,camera);
window.requestAnimationFrame(renderLoop)
}
renderLoop()
Geometries
In Three.js geometries are composed out of vertices - which are point coordinates in 3D space - and facets - which are triangles that join the vertices into surfaces.
Geometries are used to create Meshes but also for particles.
Three.js own geometries are called primitives.
Create own Geometry
If you want to create Geometry that is complex or with a precise shape it makes sense to create it in a 3D software. But for not to complex geometry we can use new THREE.BufferGeometry();
We start with instantiating a BufferGeometry
const buffGeo = new THREE.BufferGeometry()
To add vertices to the geometry we save them in a JS Float32Array
const positionsArray = new Float32Array([
0, 0, 0, // First vertex
0, 1, 0, // Second vertex
1, 0, 0 // Third vertex
])
Before you can pass the Array data into the BufferGeometry we need to transform it into a BufferAttribute.
const positionAttribute = new THREE.BufferAttribute(positionsArray,3)
The 3 defines how many values define one vertex attribute.
Finally we can this attribute to the BufferGeometry by using .setAttribute(nameAttribute,value)
geometry.setAttribute('position',positionAttribute)
The Three.js shader will look for the position name to assign the values to the position of the vertices.
Then the faces will created depending of the order of the vertices in the array.
Another example:
//Create geometry
const geometry = new THREE.BufferGeometry()
// Create Array with vertices points
//Float32 Array only allows to store Floats and the length of the array is fixed
//you also can set the length of the array with new Float32Array(9)
const vertices = new Float32Array([
-1.0, -1.0, 1.0,//First vertex
1.0, -1.0, 1.0,//second vertex
1.0, 1.0, 1.0,//third vertex
1.0, 1.0, 1.0,
-1.0, 1.0, 1.0,
-1.0, -1.0, 1.0,
]);
// pass array into BufferAttribute to store information about the position of the vertices
geometry.setAttribute('position',new THREE.BufferAttribute(vertices,3));
in .setAttribute() we also can manipulate the uvposition of the vertices, normals etc.
The THREE.JS primitives also use BufferGeometry under the hood.
Create random triangles
const geo = new THREE.BufferGeometry();
//create 50 triangles = 450 values
const count = 50;
//50 *3 *3 = 50 triangle with 3 vertex points which need 3 values
const ranTrianglePoints = new Float32Array(50*3*3);
for(let i = 0; i< count*3*3;i++){
ranTrianglePoints[i] = (Math.random()-0.5) *4
}
const positionAttribute = new THREE.BufferAttribute(ranTrianglePoints,3);
geo.setAttribute('position',positionAttribute);
Three.js Primitives
All Three.js inherit from the ButterGeometry class.
You can find all the primitive geometries from Three.JS in the documentation.
BoxGeometry
const box = new THREE.BoxGeometry({
width,
height,
depth,
widthSegments,
heightSegments,
depthSegments
})
PlaneGeometry
CircleGeometry
const geometry = new THREE.CircleGeometry(radius,segments)
SphereGeometry
ConeGeometry
const geometry = new THREE.ConeGeometry(radius,height,radialSegments)
CylinderGeometry
RingGeometry
To create a flat ring or a portion of a flat ring
const ring = new THREE.RingGeometry(innerRadius,outerRadius,numSegments)
TorusGeometry
To create a ring with thickness - like a donut
const torus = new THREE.TorusGeometry(radius,radiusTube,radialSegments,tubularSegments,arc)
Other geometries are
DodecahedronGeometry - 12 faces sphere
OctahedronGeometry - 8 faces sphere
TetrahedronGeometry - 4 faces sphere
ShapeGeometry
To create your own shapes
const x = 0, y = 0;
const heartShape = new THREE.Shape();
heartShape.moveTo( x + 5, y + 5 );
heartShape.bezierCurveTo( x + 5, y + 5, x + 4, y, x, y );
heartShape.bezierCurveTo( x - 6, y, x - 6, y + 7,x - 6, y + 7 );
heartShape.bezierCurveTo( x - 6, y + 11, x - 3, y + 15.4, x + 5, y + 19 );
heartShape.bezierCurveTo( x + 12, y + 15.4, x + 16, y + 11, x + 16, y + 7 );
heartShape.bezierCurveTo( x + 16, y + 7, x + 16, y, x + 10, y );
heartShape.bezierCurveTo( x + 7, y, x + 5, y + 5, x + 5, y + 5 );
TubeGeometry
Creates a tube that extrudes a long a 3d curve
const geometry = new THREE.TubeGeometry( path, 20, 2, 8, false );
ExtrudeGeometry
Creates extrudes geometry from a path shape.
const length = 12, width = 8;
const shape = new THREE.Shape();
shape.moveTo( 0,0 );
shape.lineTo( 0, width );
shape.lineTo( length, width );
shape.lineTo( length, 0 );
shape.lineTo( 0, 0 );
const extrudeSettings = {
steps: 2,
depth: 16,
bevelEnabled: true,
bevelThickness: 1,
bevelSize: 1,
bevelOffset: 0,
bevelSegments: 1
};
const geometry = new THREE.ExtrudeGeometry( shape, extrudeSettings );
LatheGeometry
Creates meshes with axial symmetry like vases. The lathe rotates around the Y Axis
const points = [];
for ( let i = 0; i < 10; i ++ ) {
points.push( new THREE.Vector2( Math.sin( i * 0.2 ) * 10 + 5, ( i - 5 ) * 2 ) );
}
const geometry = new THREE.LatheGeometry( points );
TextGeometry
Because it is an add-on we need to import it
import {TextGeometry} from 'three/addons/geometries/TextGeometry.js'
Three.js needs the font in a json format called typeface.
We can convert a font here
There are also fonts in the /node_modules/three/examples/fonts/ which we can put in the /static/ folder.
Another way is to directly import the json file in your script
import typefaceFont from 'three/examples/fonts/helvetiker_regular.typeface.json
To load a font we need the Three.js class FontLoader
import {TextGeometry} from 'three/addons/geometries/TextGeometry.js'
...
const loader = new FontLoader();
loader.load( 'fonts/helvetiker_regular.typeface.json', ( font ) => {
const geometry = new TextGeometry( 'Hello three.js!', {
font: font,
size: 80,
depth: 5,
curveSegments: 12,
bevelEnabled: true,
bevelThickness: 10,
bevelSize: 8,
bevelOffset: 0,
bevelSegments: 5
} );
} );
To create 3D fonts is quite some work for Three.js because of the amount of segments and vertices. Try to reduce the curveSegments and bevelSegments as much as you can.
Center the text
In Three.js geometry has a bounding which gives how much space the geometry takes in the scene. It can be a sphere(Default) or a _ box_.
We can use these boundings to position our text.
For text it makes sense to use a box as the bounding so we have to tell three.js to calculate the box
textGeo.computeBoundingBox()
console.log(textGeometry.boundingBox)
We then look for the .max properties and move the geometry inside the mesh - so the mesh stays centered in the scene.
textGeo.translate(
-textGeo.boundingBox.max.x * 0.5,
-textGeo.boundingBox.max.y *0.5,
-textGeo.boundingBox.max.z * 0.5
)
The bounding box has a bevel which we would need to subtract as well to be more precise.
textGeo.translate(
-textGeo.boundingBox.max.x * 0.5-0.02,
-textGeo.boundingBox.max.y *0.5-0.02,
-textGeo.boundingBox.max.z * 0.5-0.02
)
Three.js has a function for this to make it easier .center()
textGeo.center()
Add multiple Meshes with one call
scene.add(plane,sphere,box)
Importing geometries
GLTF is the popular standard for importing models into Three.js. It is very flexible and allows to have different sets of data. Not just for geometry and materials but also camera, light, animations etc. It also supports different file formats like binary, json and embed textures.
If you just need a Geometry it also can make sense just to use a OBJ, FBX
GLTF
GLTF can have different file formats and the most important are:
To decide which format you gonna take depends on the use case how you want to handle the assets and its data.
If you want to be able to change the data it makes sense to use the glTF-default. It also makes loading faster because the files get loaded separately.
If you don't modify anything and you just want one file to handle it makes sense to use glTF-binary.
glTF
The .gltf, the default format, is a json file that contains information about the scene like lights, cameras, objects transformations materials. It doesn't contain information about the geometries or the textures. These are stored in the a binary file .bin. This file also stores information like uvs, vertex colors and more. The textures are stored associated .png files.
When we want to load our model from a .gltf we only load that file and it links to all the other corresponding files.
glTF-Binary
This format contains all the information in just one file. This makes it a bit lighter and easier to load. But also less flexible because you can't change it's data. For example you can't just change the compression of the texture because it is implemented in the binary.
glTF-Draco
Similar to the gltf default format but the buffer data is compressed with a different algorithm - the Draco alogrithm.
It is also lighter as the default gltf
glTF-Embedded
Like the glTF-Binary just one file but it is JSON data. The benefit of this format is that you have one file which is easily editable.
Load in gltf files into THREE.JS
import {GLTFLoader} from 'three/examples/jsm/loaders/GLTFLoader.js'
const loader = new GLTFLoader();
loader.load('path',
(gltf) => {
console.log("success")
console.log(gltf);
},
(progress) => {
console.log("progress")
console.log(progress)
},
(error) => {
console.log("error")
console.log(error)
}
)
import { GLTFLoader } from "three/examples/jsm/loaders/GLTFLoader";
const hand = null;
const loader = new GLTFLoader();
loader.load("src/assets/hand.glb",(gltf)=> {
console.log(gltf.scene);
gltf.scene.rotation.y = ...
gltf.scene.position.y =
//When scaling it makes sense to scale the whole scene not just the single object
hand = gltf.scene
scene.add(gltf.scene);
})
If you gltf contains of a whole scene with multiple objects or elements we can access the single children with
gltfLoader.load(
'path',
(gltf) => {
//find the right index of child with console.log
scene.add(gltf.scene.children[indexChild])
}
)
When you move an object from one scene to another using:
scene.add(gltf.scene.children[0]);
you are simultaneously:
- Adding the first child of
gltf.scenetoscene - Removing that child from
gltf.scene
This causes the gltf.scene.children array to change dynamically as we move the objects.
If you loop through the array using a standard for loop or similar, you end up skipping elements because the array length and order change while iterating.
To avoid this we can ether use a while loop:
or instead of adding the elements from the gltf.scene we clone the children and add the clones to our Three.js scene.
This way, you are iterating over a static list and moving each child without affecting the original array during the process.
And another way is to add the whole gltf.scene
scene.add(gltf.scene)
Load Draco gltf
To load gltf-draco files we need a special DRACOLoader. We also need to add the worker code into the our three.js project by copying the Draco decoder folder(folder is located in /node_modules/three/examples/jsm/libs/) into our static folder.
We then add the path to our draco static folder
dracoLoader.setDecoderPath('/draco/')
import { DRACOLoader } from 'three/examples/jsm/loaders/DRACOLoader.js'
const dracoLoader = new DracoLoader()
dracoLoader.setDecoderPath('/draco/')
gltfLoader.setDRACOLoader(dracoLoader)
To decide if you use Draco or not depends of the size of your project. If you just have a small geometry file we don't need Draco. But if you want to load bigger models and you can accept can freezes at the beginning you should consider Draco.
Access Childs of element
firstFrameRoom = paintingG3.getObjectByName("firstFrameRoom");
secondFrameRoom = paintingG3.getObjectByName("SecondFrameRoom");
thirdFrameRoom = paintingG3.getObjectByName("ThirdFrameRoom");
if (firstFrameRoom) {
console.log("First Frame Room Mesh:", firstFrameRoom);
// You can manipulate the mesh here
firstFrameRoom.material.color.set(0xff0000); // Change color to red
}
if (secondFrameRoom) {
console.log("Second Frame Room Mesh:", secondFrameRoom);
// Example of moving the mesh
secondFrameRoom.position.set(1, 0, 0);
}
if (thirdFrameRoom) {
console.log("Third Frame Room Mesh:", thirdFrameRoom);
// Example of changing visibility
thirdFrameRoom.visible = false;
}
paintingG3.traverse((child) => {
console.log(child.name); // Log the name of each child
if (child.isMesh) {
console.log("Found a mesh:", child);
}
});
// Accessing a specific child by name or index
const firstChild = paintingG3.children[0];
console.log("First child:", firstChild);
Access Animations of gltf
GLTF supports animations.
The gltf object has an animation property which contains AnimationClip
To play an AnimationClip we need to create an AnimationMixer.
Each object that gets animated needs its own AnimationClip.
const mixer = null;
const loader = new GLTFLoader();
loader.load("path",(gltf)=> {
...
mixer = new THREE.AnimationMixer(gltf.scene);
//adding AnimationClips to mixer
const animationAction = mixer.clipAction(gltf.animations[0])
animationAction.play();
})
//mixer must update each frame
const tick = () => {
...
if(mixer){
mixer.update(deltaTime);
}
}
Particles
With particles we can do dust, rain, snow, stars etc. Each particle is one plane build out of two triangles which is always facing the camera.
Geometry
For the Geometry in Particles we use BufferGeometry which exists for all the standard mesh geometries like SphereBufferGeometry etc. BufferGeometry is more performant so it is better to use for Particles.
For every vertex on the BufferGeometry we gonna get one particle.
const particleBaseShape = new THREE.SphereBufferMaterial(radius,widthSubdivision,heightSubdivision)
Material
For the Material we can use the PointsMaterial which is optimized for particles and has also specific properties like
size and sizeAttenuationfor particles.
size control the size of all particles
sizeAttenuation - should particles that are farther away be smaller than closer ones.
To change the color of the particle you can use the color property. We need to use the THREE.Color class for that after we created already the material.
pointsMaterial.color = new THREE.Color('#ff88cc')
Similar to the other materials we also can load and assign a Texture to the particles.
pointsMaterial.transparent = true
If you only want to keep the alpha values of the texture you can use the .alphaMap
pointsMaterial.alphaMap = partTexture
If you want to have the whole texture assign it to .map
The color property will affect the Texture.
Different Colors for each particle
To create varying colors for each of the particles we need to add a new BufferAttribute color. Then
we can use the same for-loop to assign for example random colors and set the Attribute at the end.
//Again here 3 because we have r,g,b values
const positions = new Float32Array(count*3);
const colors = new Float32Array(count*3);
for(let i = 0; i<count;i++){
colors[i] = Math.random();
positions[i] = (Math.random()-0.5)*10
}
particles.setAttribute('position',new THREE.BufferAttribute(positions,3));
particles.setAttribute('color',new THREE.BufferAttribute(colors,3));
//At the end we need to active vertex colors in the material
particlesMaterial.vertexColor = true
//Deactivate particlesMaterial.color = new THREE.Color...
Improving order of displaying particles
WebGL is drawing in the same order how the particles got created and it doesn't know which particle is front of the other.This can cause some render artifacts. We can use different ways to improve this.
Alpha Test
With the alpha test we test if a pixel gets rendered or not depending on it's transparency. The alpha test defines that every pixel under a threshold value is not gonna be rendered. The default threshold is 0 so every pixel will be rendered. By changing it to like 0.001 we exclude all the pixel from being rendered that have an alpha value from 0.
pointMaterial.alphaTest = 0.001
DepthTest
When rendering Three.js test if that object that gets drawn is closer than other already drawn object.
This is called Depth testing.
particlesMaterial.depthTest = false to disable.
Turning depthtesting of can create problems with other non particle objects in the scene.
DepthWrite
Three.js stores the depth of what is being drawn in a depth buffer. We can tell Three.js not to write the particles in the depth buffer.
particlesMaterial.depthWrite = false
Deactivating the depthWrite often can fix your problems.
Blending
To create a nice effect when your particles overlap we can use Blending.
particlesMaterial.depthWrite = false
particlesMaterial.blending = THREE.AdditiveBlending
The downside of this is that it can affect the performance of you scene.
You can find some particle textures here;
Instead of creating an instance of Mesh we use Points instance.
const particles = new THREE.Points(particleGeo,particleMat)
Custom Geometry
To create our own geometry we start with a BufferGeometry, set the positions in an Float32Array and then assign
the values to the position attribute of the BufferGeometry
const partGeo = new THREE.BufferGeometry();
const count = 500;
const positions = new Float32Array(count*3);
for(let i = 0; i< count;i++){
positions[i] = (Math.random()-0.5) * 10;
}
partGeo.setAttribute('position',new THREE.BufferAttribute(positions,3));
Animation
There are multiple ways to animate particles.
Using Points as an object
You can move, scale, rotate the Points class like the other geometry.
const tick = () => {
const elapsedTime = clock.getElapsedTime()
particles.rotation.y = elapsedTime * 0.3;
}
This will animate all the particles as a whole.
Changing Attributes of Particles
To move the individual particles/ update the vertex positions, we have to change the position attribute of the Particle system.
The positions in the Float32Array are stored in an one dimensional array
[p0.x,p0.y,p0.z,p1.x,p1.y,p1.z,...]. If you for example only want to change all the y positions of the vertex
you need to loop through the array in certain steps.
const tick = () => {
// ... elapsed time
for(let i = 0; i< count;i++){
const i3 = i*3;
//Move all the particles y position on Math.sin()
particlesGeometry.attributes.position.array[i3+1] = Math.sin(elapsedTime);
}
//We need to notify Three.js that the vertices changes
particlesGeometry.attributes.position.needsUpdate = true;
}>
To get now the individual y positions depending on the x positions on the sin wave we need to get
the x position of the particle and add it to the elapsedTime in the Math.sin
const tick = () => {
const elapsedTime = clock.elapsedTime()
for(let i = 0;i<count;i++){
const i3 = count*3;
const x = particlesGeometry.attributes.position[i3];
particlesGeometry.attributes.positions[i3+1] = Math.sin(elapsedTime+x);
}
particlesGeometry.attributes.position.needsUpdate = true;
}
The problem with this technique is that is super costly on the performance because on every frame we are looping through the entire array
It is more performant to create custom shaders.
Optimization
Fog
To create fog around the center
scene.fog = new THREE.Fog(0x000000,15,25);
You then should also set the renderer clear color to the fog color
renderer.setClearColor('0x000000');
Calculate distance camera and a certain mesh
We can use the distanceTo function to calculate it.
So we actually can trigger something if the camera reaches an object. If the distance is < than show something
Delete Margin of Three.JS scene
Deletes the margin and the scrollbar
Controls
Controls
Three.JS has a lot of different already pre-build controls integrated which you can use for interactions.
DeviceOrientationControls: Retrieves the device orientation of your device allows it and it rotates the camera accordingly.
FlyControls: Enables you to move the camera like if you were on a spaceship. You can rotate on all 3 axes, go forward and backward.
FirstPersonControls: Like the FlyControls but just with a fixed up axis. Like a flying bird that can't do a barrel roll.
PointerLockControls: Its a JS API that hides the cursor, centers it, keeps sending the movement in the mousemove event callback. It allows you to create FPS games. But it just handles the camera rotation. Your have to do the camera position yourself.
OrbitControls: Allows you to rotate around a point with the left mouse btn and translate with the right mouse btn, and zoom in with the mouse wheel.
TrackballControls: They are similar to OrbitControls but without any limits for the vertical angle which allows upside down rotations.
Orbit Controls
To import OrbitCamera we need to import it into our sketch
import {OrbitControls} from 'three/addons/controls/OrbitControls.js'
Then set it in the code
import {OrbitControls} from 'three/addons/controls/OrbitControls.js'
const controls = new OrbitControls(camera,canvas);
//update controls in animate
function animate () {
//required if controls.enableDamping or controls.autoRotate set to true
controls.update();
}
By default the OrbitControls is looking at the center of the scene.
With the target property we can change where it is looking.
controls.target.y = -2
To smooth the animation of the OrbitControls we can use .enableDamping property and set it to true
controls.enableDamping = true
controls.dampingFactor = 0.03;
To let the orbit controls automatically rotate we can set
controls.autoRotate = true;
Map controls
Fly controls
Fly Controls The camera follows where the mouse is without clicking thing mouse
First Person controls
It goes under pointerlock in the examples.
const controls = new PointerLockControls(camera, document.body);
controls.addEventListener('lock', function () {
menu.style.display = 'none';
});
controls.addEventListener('unlock', function () {
menu.style.display = 'block'
}
Drag controls
Drag elements Trackball Controls
Trackball controls
Camera
By default, in Three.js the field of view is vertical meaning if you put objects at the top and bottom and then rescale your window you still see them at the top and bottom part - they don't disappear.
PerspectiveCamera
FOV: The field of view is how large your vision angle is.
The bigger that angle the more you can see from the scene/experience but also the elements in that scene get smaller and more distorted.
The smaller the angle the less you can see from the scene but the elements are gonna appear larger.
In conventional photography a lot of people use 50° or 35° field of view. Play with values between 45 and 75
const camera = new THREE.PerspectiveCamera()
Aspect Ratio- In most cases the width of the canvas divided by the height.
Near - Anything within the distance between your camera and the near property you won't be able to see. Stick with numbers like 0.1 or 0.3. Values can be imagined in meters Far - Anything after the distance between your camera and the far property you won'T be able to see. Stick numbers like 200.
Define how far/close orbin camera can move
const controls = new OrbitControls(camera,renderer,domElement);
controls.minDistance = 5;
controls.maxDistance=15;
Look at specific target with orbit camera
controls.targer.set(0,0,0)
Orthographic camera
For orthographic renders without perspective. Elements will have the same size on the screen regardless of their distance from the camera. All the lines are parallel. The values that the camera asks are the distance between the center of the camera and the outer edges of the box. The orthografic camera requires: left:left edge right:right edge top:top edge bottom:bottom edge near: far:
To not get a distortion of your elements we need to multiple the left and right values with the aspect aspectRatio
const aspectRatio = window.innerWidth/window.innerHeight
const orthoCamera = new THREE.OrthographicCamera(
-1*aspectRatio,
1 * aspectRatio,
1,
-1,
0.1,
200
)
camera.position.z = 5
Change the aspect of the camera
camera.aspect = 4
Render Multiple Camera
ArrayCamera
To render multiple cameras performant for example for VR we can use
ArrayCamera
Each camera will render a specific area o the canvas.
StereoCamera
The StereoCamera is used to render the scene through two camera that mimic the eyes in order to create a parallax effect. You need a VR headset or red and blue glasses to see the result.
CubeCamera
The CubeCamera is used to get a render facing each direction(forward, backward, leftward, rightward, upward, and downward) to create a render of the surrounding. You can use it to create an environmentmap for reflection or a shadow map.
Materials
Materials are used to put color on each visible pixel of the geometry. We write the algorithms that decide which color gets displaced at which pixel in shaders.
We can use one material for multiple meshes.
Mesh Basic Material
THREE.MeshBasicMaterial is a material that doesn't react to light.
const material = new THREE.MeshBasicMaterial({
//We ether can assign colors by name or by hexadecimal color: 0xff0000, or even by an instance off the Color class
color: 'red',
transparent:true,
opacity:0.5,
})
// We also can change the properties after creating the Material
const material = new THREE.MeshBasicMaterial({
color:'red'
})
material.transparent =false;
material.color = new THREE.Color(0xff00ff);
There are multiple ways to set the color:
material.color = new THREE.Color('#ff0000')
material.color = new THREE.Color('#ff00')
material.color = new THREE.Color('red')
material.color = new THREE.Color('rgb(255,0,0)')
material.color = new THREE.Color('0xff0000')
Set transparency of material
Control transparency with texture
To be able to use an alpha mat on an object we need to enable transparency of the material
Changing sites of material
Three.JS by default has one side materials. So with a plane if you Rotate it 180° you wouldn't see the backside of the shape.
For that we can use THREE.DoubleSide
material.side = THREE.DoubleSide
THREE.DoubleSide is a Three.JS constant so we don't need to use new
If not necessary try to avoid DoubleSide because it raises the number of triangles to render.
THREE.BackSide when you want to show the Backside instead.
Turn of/on if material reacts to fog
Materials react by default to fog. We can change that with
material.fog = false
Changing all materials of scene or object
scene.traverse((child) => {
if(child instanceof THREE.Mesh && child.material instanceof THREE.MeshStandardMaterial){
child.material.envMap = environmentMap;
...
}
})
Wireframe Material
We set a property inside the Material wireframe: true
MeshLambert Material
The MeshLambert material is a really performant material but also has less realism and options.
It requires information from light.
MeshPhong Material
With a MeshPong Material we get a light reflection/shininess property. The higher the value the more shiny is the material.
material.shininess = 90
To change the color of the reflection we can use the .specular property.
material.specular = new THREE.Color("0xff0000")
MeshStandardMaterial
The MeshStandardMaterial is based on Physically based rendering(PBR) and gets used a lot in Three.js.
The material gets effected my light and allows to use properties like roughness and metalness.
const material = new THREE.MEshStandartMaterial();
material.color = new THREE.Color("blue");
material.map = colorTexture;
material.roughness = 0.3;
material.metalness = 0.6;
The MeshStandardMaterial also allows to add ambient oclussion maps. These add shadows where the texture of the map is dark. So we create more contrast around the dark parts of the texture.
The aoMap requires a second set of uvs.
myGeo.geometry.setAttribute('uv2',new THREE.BufferAttribute(myGeo.geometry.attributes.uv.array,2))
material.aoMap = ambientOcclusionTexture
material.aoMapIntensity = 1
In a MeshStandardMaterial we also can add a displacementMap to displace the vertices of the geometry. It is important that the geometry has enough vertices to work with otherwise it is gonna look weardly distorded.
material.displacementMap = displaceTex
material.displaementScale = 0.05
For the metalness and the roughness we can assign maps
material.metallnessMap = metalNessTexture
material.roughnessMap = roughnessTexture
If the result doesn't look as expected reset the metalness and roughness properties
material.metalness = 0
material.roughness = 1
We also can add the material specific normal map to add details without having a high subdivision of the geometry
material.normalMap = normalTexture
material.normalScale.set(0.2,0.2)
MeshPhysicalMaterial
The MeshPhysical material has same properties like the MeshStandard but
has more properties like reflectivity and clearcoat
reflectivity allows you to have a reflective material which has a low metalness value.
const material = new THREE.PhysicalMaterial();
material.color = new THREE.Color(0xff33ff);
material.reflectivity = 0.3;
clearcoat is like a reflective gloss or like a wax on the car.
material.clearcoat = 0.9
MeshNormalMaterial
This materials shows the normals of the object.
const normalMat = new THREE.MeshNormalMaterial()
MeshNormalMaterial has also the property .flatShading which allows us to flatten the faces of the geometry - normals won't be interpolated between the vertices.
MeshToonMaterial
The MeshToonMaterial is similar to the MeshLambertMaterial but creates a more toon style.
material = new THREE.MeshToonMaterial()
It creates a coloration with two steps - one for light and one for shadow.
With a gradient texture we can get more color steps.
material.gradientMap = gradientTexture
When the gradient texture is small Three.JS is not automatically picking the nearest pixel on the texture but is interpolating the pixel colors. In the case of MeshToonMaterial we want to prevent that.
To make it work we need to set .minFilter, .magFilter and deactivate the generation of mipmaps
gradientTexture.minFilter = THREE.NearestFilter
gradientTexture.maxFilter = THREE.NearestFilter
gradientTexture.generateMipMaps = false
MeshMatcapMaterial
The MeshMatcapMaterial can create a nice look while being very performant. It needs a texture that looks like a sphere
The normal orientation relative to the camera decides which color the material is gonna pick for the vertex.
MeshDepthMaterial
The MeshDepthMaterial will color the parts of a material according to the closeness of the pixel to the camera.
If can be useful if you want to create effects where you need to know how far the pixel is from the camera.
PointsMaterial
When you work with particles it makes sense to use the PointsMaterial
ShaderMaterial
To create material for your geometries from shaders you can use ShaderMaterial and RawShaderMaterial
Environment map
With environment maps we can add images of the surrounding scene. They create more realistic reflection or refraction for your materials and lighting. We can use environment maps as a background or on the objects as reflection and lightning.
To add the environment map to our material we use the .envMap property.
Three.js only supports cube environment maps. They contain 6 images each for one side of a environment.
To load a cube environment map we use CubeTextureLoader
const cubeTextureLoader = new THREE.CubeTextureLoader()
const environmentMapTexture = cubeTextureLoader.load([
'/textures/environmentMaps/px.jpg',
'/textures/environmentMaps/nx.jpg',
'/textures/environmentMaps/py.jpg',
'/textures/environmentMaps/ny.jpg',
'/textures/environmentMaps/pz.jpg',
'/textures/environmentMaps/nz.jpg'
])
material.envMap = environmentMapTexture
You can find environment maps on Poly Haven
But you need to convert the HDRI into a cubemap with HRDI to Cubemap.
Maybe convert the png into jpg
To apply an environment map to the whole scene as a background we can assign the map to the scene itself
scene.background = envMap
scene.environment = envMap
To get a more realistic render it is essential to add an environment map to lighten the model itself.
Intensity
When the objects look to dark we can increase the environmentintensity property
scene.environmentIntensity = 3
Bluriness
To blur the background we can change backgroundBlurriness property.
scene.backgroundBlurriness = 0.2
Brightness
To alter the intensity of the background we can change backgroundIntensity
scene.backgroundIntensity = 4
Rotation
If you want to change the rotation of your environment map you can change the backgroundRotation and the environmentRotation properties.
scene.backgroundRotation.y = 2
scene.backgroundRotation.y = 3
Be aware of changing the x and z axis because normally you want the floor stay on the bottom
HDR
"High Dynamic Range Image"(HDRI) have a higher range of color values stored in the image - for example luminosity.
They are often equirectangular but don't have to be.
To load HDRI we neet to import the RGBELoader
import { RGBELoader } from 'three/examples/jsm/loaders/RGBELoader.js'
RGBE is the encoding for the HDRI images.
The E stands for exponent which stores the brightness.
const rgbeLoader = new RGBELoader();
rgbeloader.load('/environmentMaps/../name.hdr',(envMap) => {
console.log(envMap)
envtMap.mapping = THREE.EquirectangularReflectionMapping
scene.background = envMap;
scene.environment = envMap;
})
The only problem with hrds is that they are more costly for the performance. Using lower resolutions and blurring the background can help to reduce the performance impact.
To import exrfiles we need a different loader
import { EXRLoader } from 'three/addons/loaders/EXRLoader.js'
const exrLoader = new EXRLoader()
exrLoader.load("path",(envMap) => {
envMap.mapping = THREE.EquirectangularReflectionMapping
scene.background = environmentMap
scene.environment = environmentMap
})
For jpg environment maps set the colorSpace for the environment map to THREE.SRGBColorSpace and
maybe increase the environmentIntensity of the scene.
envMap.colorSpace = THREE.SRGBColorSpace
scene.environmentIntensity = 2
Also we need to load the texture with THREE.TextureLoader()
Grounded environment map
The problem with environment maps is that when we have an object in the center and we want to use the environment actually as a background texture than the object always seem to fly - the object is too far away from the floor.
For that we can use ground projected skybox
import {GroundedSkybox} from 'three/addons/objects/GroundedSkybox.js'
We then initiate a GroundedSkybox(envMap,15,70) in the callback of the environmentmap loader.
rgbeLoader.load('path',(envMap)=> {
//...
const skybox = new GroundedSkybox(envMap,15,70)
scene.add(skybox);
})
This creates a sphere that is squished at the bottom so the center of the scene is closer to the bottom of the GroundedSkybox
We then adapt the y-position of the sphere to match with the scener of the scene
Setting the skybox.material.wireframe true makes the positioning easier.
Real-time environment map
We also can render every frame of the scene, store the render in a render target and then apply it as a environmentmap to the scene. This allows us to have a real-time environmentmap.
So we render the scene to a THREE.WebGLCubeRenderTarget() and assign that texture to the scene.environment
const cubeRenderTarget = new THREE.WebGLCubeRenderTarget(
256,//Resolution of each side
{
//Properties to set the render Target
type:THREE.FloatType//32 bits to save information
//type:THREE.HalfFloatType //16 bits to store information
}
)
scene.environment = cubeRenderTarget.texture
We then create a CubeCamera to render all 6 sides of the scene.
THREE.CubeCamera(near,far,WebGLCubeRenderTarget)
const cubeCam = new THREE.CubeCamera(0.1,100,cubeRenderTarget)
Then on every frame we render the camera with
cubeCamera.update(renderer,scene)
//loading base environmentmap
...
const cubeRenderTarget = new THREE.WEbGLCubeRenderTarget(
256,
{
type:THREE.FloatType
}
)
scene.environment = cubeRenderTarget.texture
//Creating a light donut
const lightDonut = new THREE.Mesh(
new THREE.TorusGeometry(8,0.5),
new THREE.MeshBasicMaterial({color: new THREE.Color(10,4,2)})//When you have a high-range texture you can use color values beyond 1
)
scene.add(lightDonut)
const clock = new THREE.Clock();
const tick = () => {
const elapsedTime = clock.getElapsedTime()
lightDonut.rotation.x = elapsedTime;
lightDonut.rotation.y = elapsedTime;
lightDonut.rotation.z = elapsedTime;
}
To decide which objects get included in the rendering of the camera and which get's ignored we can create Layers.
So by setting layers on a camera it will only show the objects that have the same Layer. By default all camera and object layers are set to 0.
To add a layer object.layers.enable()
To remove a layer object.layers.disable()
To only enable one layer and disable all others object.layers.set()
So if you want an real-time environmentmap with moving lightning you would set the lighning source and ignore all other objects.
cubeCamera.layers.set(1)
lightDonut.layers.set(1)
Normals
Normals contain information about the direction of the outside of the face on each vertex of the mesh. You can image normals as arrows coming out of the vertex of the geometry and pointing into a direction.
The material will then pick colors on the texture according to the normal orientation relative to the camera.
material.matcap = matcapTexture
You can find a big list of matcaps here
To create your own matcap material you can render a sphere in front of a camera into a squared image.
Textures
What are Textures?
Textures are images that will cover the surface of your geometry. There are different textures that create certain effects on the appearance of the object.
Color/Albedo: It takes the pixel of the texture and applies it to the geometry
Alpha: A grayscale image where the white parts define that the texture will be shown and the black parts won't.
Height: A grayscale image that moves the vertices of the geometry to create a relief effect. For that your geometry needs certain subdivision to be able to create the relief.
Normal: Adds details but doesn't actually changes the geometry. It basically fakes to the light source that some faces of the geometry are oriented in a certain direction. Good way to add details without subdividing your geometry.
Ambient Occlusion: Grayscale image that fakes shadow on the surface of the geometry.
Metalness: Grayscale image that specifies which parts of the geometry are metallic(white) and which parts are not(black)
Roughness: Grayscale image that defines which parts of the surface are rough(white) or smooth(black)
These textures we use to apply Physically Based Rendering(PBR) to our scene to create realistic renders.
We can get good free materials at FreePBR.com
To load the textures into THREE.JS we need to first initialize a loader that loads the textures.
More information about PBR here and here
Loading Textures
There are different ways to load textures.
Loading with native JS
With JS we need to create an Image instance, listen to the load event and the assign it to the src of the Image.
const Image = new Image()
const texture = new THREE.Texture(image)
Image.addEventListener('load',()=> {
texture.needsUpdate = true
})
image.src = 'textures/.../filename.png'
// we then assign the texture to the map property of the material
const material = new THREE.MeshBasicMaterial({texture})
Using Texture Loader
//Only create this once - even if you use the loader more often - its a utility class
const texLoader = new THREE.TextureLoader();
// initialize the texture
const texture = textureLoader.load('path/to/file')
// assign texture to map property of a material
const material = new THREE.MeshStandardMaterial();
material.map = texture;
material.roughnessMap = textureRoughness;
material.roughnessMap = 0.1 // won't effect parts of the texture that aren't rough we only apply this value to the parts that are specifies as roughness
material.metalnessMap = textureMetall;
material.normalMap = normal; // normalmap holds information about how to fake the way light bounces of of this material.
material.displacementMap = heightMap; //The heightmap actually displaces the vertices of the Mesh
material.displacementScale = 0.1;
/*ambient occlusion is technique to add more depth and realism to the scene. it simulates how light is occluded or blocked where elements are close together or one elements throws shadows on another.
the ao map requires a second set of uvs. We can pass them from the actual geometry*/
const uv2 = new THREE.BufferAttribute(geometry.attribute.uv.array,2)//2 is for the item size x and y
geometry.setAttribute('uv2',uv2);
)
material.aoMap = grassAo;
material.aoMapIntensity = 1
We also can call this directly in the material initiation
const loader = new THREE.TextureLoader();
const material = new THREE.MeshStandardMaterial({
map = loader.load("path")
})
If the loading of your functions not worked as you expected, in the .load function we can call three functions to control if the loading of the function worked properly.
textureLoader.load("path",
() => {
console.log('loading finished')
},
() => {
console.log('loading progressing')
},
() => {
console.log('loading error')
}
)
Using Loading Manager
When you want to load multiple textures and be notified after the successful load we can also use the LoadingManagerclass and pass it into the TextureLoader
const loadingManager = new THREE.LoadingManager();
const textureLoader = new THREE.TextureLoader(loadingManager)
// you the can listen to the different events of the Loading manager
loadingManager.onStart = () => {
console.log('loading started')
}
loadingManger.onLoaded = () => {
console.log('loading finished');
}
loadingManager.onProgress = () => {
console.log('loading progressing')
}
loadingManger.onError = () => {
console.log('loading error');
}
UV unwrapping
UV Unwrapping defines how the texture is wrapped around the surface of the geometry. Each vertex has a 2D coordinate on a flat square plane that defines which part of the texture will displaces at that vertex position.
To see the uv coordinates you can use the
geometry.attributes.uv property.
Three.js creates these uv properties for it's primitives. But if you create your own geometry in a 3D software or you import geometry you need specify the uv coordinates and need to to the uv unwrapping yourself.
UV Maps
A UV Map tells THREE.js how to map a texture on an object. By default THREE.js maps textures differently than blender. Blender wraps a texture over all sides of an object. Three.js maps the whole texture on one face.
Transforming the texture
Repeat
Especially if you use texture on bigger surfaces it can make sense to change the repeat of the texture otherwise it gets streched a lot.
Lets repeat this texture 10 times x and 10 times y
texture.repeat.x = 10
texture.repeat.y = 10
texture.repeat.set(10,10)
To make this work we need to set the wrapS and wrapT property of the texture.
Another type of wrapping is THREE.MirrorRepeatWrapping
Offset
We can offset the texture with the offset property.
texture.offset.x = 0.5
texture.offset.y = 0.5
Rotation
To rotate the texture we use the rotation property.
texture.rotation = Math.PI *0.25
The rotation occurs around the bottom left corner which is the 0,0 uv coordinate.
To change the pivot point of the rotation you can use the center property
Filtering and Mipmapping
Mipmapping creates smaller versions of the texture - always halfed in size till 1x1. The GPU the picks the right texture for the render. Three.js and the GPU handle this and we can decide which algorithm to use for that. There are two types of filter alogrithms:
Minification
The minification filter happens when pixels of the texture are smaller than the pixels of the render or the texture is to big for the surface it covers. Different filter:
THREE.NearestFilter
THREE.LinearFilter
THREE.NearestMipmapNearestFilter
THREE.NearestMipmapLinearFilter
THREE.LinearMipmapNearestFilter
THREE.LinearMipmapLinearFilter//Default filter
To set the filter
texture.minFilter = THREE.NearestFilter
Magnification Filter
Magnification filter works when the pixels of the texture are bigger thant the renders pixel - the texture is too small for the surface.
The texture gets then blurry because it gets stretched on the large surface.
Filter:
THREE.NearestFilter
THREE.LinearFilter//Default
texture.magFilter = THREE.NearestFilter
Generally THREE.NearestFiler is computationally cheaper than the other filter.
Also only mipmaps for the minFilter property. If you are using THREE.NearestFilter you don't need mipmaps and you can deactivate them with
texture.generateMipmaps = false
texture.minFilter = THREE.NearestFilter
This will creates less load for the GPU.
Texture Format and optimisation
Be aware of 3 factors when you prepare your textures: Weight Size/Resolution Data
Weight
The users that are going to your website are going to download the textures. Use .jpg(lossy compression but lighter) or .png(lossless compression but heavier) for your files.
Try to get an acceptable image but as light as possible TinyPNG can help.
Size
Try to reduce the size of the images as much as possible because every pixel of the image needs to get stored on the GPU - and with mipmapping even more pixel.
The size of your texture must have a power of 2
512x512 1024x1024 512x2048
or otherwise Three.js have to stretch the texture to the next power of two.
Data
For normal textures it makes sense to use png so you get a lossless compression.
Sources
To get good textures you can go to Poliigon 3Dtextures.me
GLSL as Material
function createBackMaterial() {
let m = new THREE.MeshBasicMaterial({
color: 0x66775f,
side: THREE.BackSide,
onBeforeCompile: (shader) => {
shader.fragmentShader = `
${shader.fragmentShader}
`.replace(
`vec4 diffuseColor = vec4( diffuse, opacity );`,
`
vec3 col = mix(diffuse, diffuse + vec3(0.75), smoothstep(0.5, 0.7, vUv.y));
vec4 diffuseColor = vec4( col, opacity );
`
);
console.log(shader.fragmentShader);
},
});
m.defines = { USE_UV: "" };
return m;
};
Displace material via displacement map
const textureLoader = new THREE.TextureLoader();
const displacementMap = textureLoader.load(`src/assets/img/height.png`)
displacementMap.wrapS = displacementMap.wrapT = THREE.RepeatWrapping;
Blending Materials
We can blend the materials of the different objects when we set
blending:THREE.AdditiveBlending for the materials.
Scene
The scene object has .children property which allows us to access the children of the scene and more importantly
loop through all the children of the scene.
scene.children.forEach((child) => {
//Test if child is actually a mesh
if(child instanceof THREE.Mesh){
child.rotation.x += 0.01;
}
})
To be more performant because you don't want to loop through all the children on every frame you create a group add that to the scene and then loop through the children of the group. Now we only loop through the elements that we really want to.
...
const group = new THREE.Group();
group.add(plane,sphere,cylinder);
scene.add(group);
group.children.forEach((child)=> {
if(child instance of THREE.mesh){
child.rotation.x +=0.2;
}
})
Group
If you have multiple objects that belong together and maybe need to be transformed together it can make sense to group them together with the Group class which inherits also from Object3D.
You then can add objects to the group
const boxGeo = new THREE.BoxGeometry(1,1,1);
const boxMat = new THREE.MeshBasicMaterial({color:0xff0000})
const mesh = new THREE.Mesh(boxGeo,boxMat);
group.add(mesh)
Frustum Culling
Three.js calculates if the geometry is on the screen and if not the object won't be rendered.
Light
AmbientLight
In reality light reflects of all the surface.
To create some light even behind our objects we want to add an AmbientLight to the scene.
const ambLight = new THREE.AmbientLight(0xffffff,0.2);
ambLight.intensity = 0.5;
scene.add(ambLight);
Point Light
A Point Light has a small light source and spreads uniformly in every direction
const pointLight = new THREE.PointLight(color,intensity)
const pointLight = new THREE.PointLight(0xffffff,1);
pointLight.position.set(5,5,5);
scene.add(pointLight);
We also can control how the intensity of the light fades and how fast it is fading
const pointLight = new THREE.PointLight(color,intensity,distance,decay)
const pointLight = new THREE.PointLight(0xff0000,0.5,8,5)
DirectionalLight
If you want a light like the sun you can use a THREE.DirectionalLight('color',intensity)
To have it shine more from the side we move it
directionalLight.position.set(1,0.2,0.);
We also can set the target of the directional light with the target property
directionalLight.target.position.set(0,5,0)
directionalLight.target.updateWorldMatrix()
HemisphereLight
The HemisphereLight is similar to the AmbientLight but it emits a different color from the ground than from the sky.
const hemLight = new THREE.HemisphereLight('colorSky','colorGround',intensity)
You also can add flatShading:true as a parameter.
RectAreaLight
Works like a rectangle light. It mixes directional light with diffuse light.
const rectAreaLight = new THREE.ReactAreaLight(color,intensity,widthRect,height)
const rectAreaLight = new THREE.RectAreaLight(0x0000ff, 2, 1, 1)
This light only works with MeshStandardMaterial and MeshPhysicalMaterial
rectAreaLight.position.set(-2,0,1)
// to look at center of the scene
rectAreaLight.lookAt(new THREE.Vector3())
SpotLight
Works like a flashlight with a cone of light starting at a point and oriented in one direction.
distance - At which distance drops intensity to 0
angle - How big is the beam
penumbra- How diffused is contour of the beam
decay - how fast does the light dim
const spotLight = new THREE.SpotLight(color,intensity,distance,angle,penumbra,decay)
const spotLight = new THREE.SpotLight(0xff0022,0.5,10,Math.PI * 0.1,0.25,1)
To rotate the SpotLight we have to add its .target to the scene
const spotLight = new THREE.SpotLight(0xff0022,0.5,10,Math.PI*0.1,0.25,1);
spotLight.position.set(0,3,2);
spotLight.target.position.x = -0.5;
scene.add(spotLight.target);
Performance optimizations
Try to add as few lights as possible and use the light that has the lowest performance cost because lights are intensive to compute.
Minimal Cost:
- AmbientLight
- HemisphereLight Moderate cost:
- DirectionalLight
- PointLight High Cost
- SpotLight
- RectAreaLight
Baking lights
Baking is a technique where we already can bake in the lightings of the scene into the material texture so we don't need real time lighting.
Light Helpers
We can use Three.js helpers to see how the lights are positioned
const hemisphereLightHelper = new THREE.HemisphereLightHelper(hemisphereLight,0.2);
scene.add(hemisphereLight);
const directionalLightHelper = new THREE.DirectionalLightHelper(diretionalLight,0.2);
scene.add(directionalLight);
const pointLightHelper = new THREE.PointLightHelper(pointLight,0.2);
scene.add(pointLightHelper)
const spotLightHelper = new THREE.SpotLightHelper(spotLight);
scene.add(spotLightHelper);
//needs to be updated
window.requestAnimationFrame(()=> {
spotLightHelper.update();
})
import { RectAreaLightHelper } from 'three/examples/jsm/helpers/RectAreaLightHelper.js'
const rectAreaLightHelper = new RectAreaLightHelper(reactAreaLight)
scene.add(rectAreaLightHelper)
//needs to be updated
window.requestAnimationFrame(() =>
{
rectAreaLightHelper.position.copy(rectAreaLight.position)
rectAreaLightHelper.quaternion.copy(rectAreaLight.quaternion)
rectAreaLightHelper.update()
})
Shadows
The goal with shadows is to draw realistic shadows with keeping a reasonable frame rate. How Three.js creates shadows is it first does a render for each light that is suppose to create shadows. These renders simulate what the light sees - similar to what a camera sees. It then creates a MeshDepthMaterial that replaces all meshes materials. The result is stored as a shadow maps texture. These are used on every material that is supposed to receive shadows.
To activate shadows we set them in the renderer
renderer.shadowMap.enabled = true
We then decide for each object in the scene if it can cast shadows or not and set the property castShadow to true.
geo.castShadow = true
At the end we also have to activate the shadows on the light sources.
directionalLight.castShadow = true
PointLight,DirectionalLight,SpotLight allow to activate shadows.
Optimization of shadow maps
Generally one problem with shadow maps in Three.js is that it handles every shadow map for every object by itself so if you have multiple objects it doesn't merge the shadows of different objects.
Beware of settings to many PointLights with shadows in your scene. Three.js creates a cube shadow map and has to render 6 shadow map textures for each side of the directions.
Size of Render
To improve the shadows we can access the shadowMap property to change the size of the shadowmap
directionalLight.shadowMap.mapSize.width = 1024
directionalLight.shadowMap.mapSize.height = 1024
Near and far
If you have a situation where your shadow is cropped or you can't see the shadow at all it can be a problem of near and far. Three.js uses Cameras to render the shadow map so the near and far values of these cameras can cut off the shadow.
We can access the camera that is used for a shadow map with light.shadow.camera
To see the near and far values it can be useful to use a
CameraHelper
const lightCameraHelper = new THREE.CameraHelper(light.shadow.camera)
scene.add(lightCameraHelper)
We then can adjust the near and far values
light.shadow.camera.near = 1
light.shadow.camera.far = 6
Amplitude
For DirectionalLight Three.js uses a OrthographicCamera. We can adjust and reduce the field of view to create more accurate shadows - the smaller the values the more accurate the shadows - but only reduce the values till you cut off your shadows.
directionalLight.shadow.camera.top = 2
directionalLight.shadow.camera.right = 2
directionalLight.shadow.camera.bottom = -2
directionalLight.shadow.camera.left = -2
For SpotLight Three.js uses a Perspective Camera so have to set the field of view .fov property.
spotLight.shadow.camera.fov = 20
Blur
To reduce the sharp edges of your shadow if can make sense to add some blur to your shadows.
light.shadow.radius = 5
Shadow map algorithm
Three.js has different types of shadow map algorithms that we can use:
THREE.BasicShadowMap- Very performant but low qualityTHREE.PCFShadowMap- Less performant with smoother edgesTHREE.PCFSoftShadowMap- Less performant but edges are even smootherTHREE.VSMShadowMap- Less performant
We can set the shadow map algorithm with renderer.shadowMap.type = THREE.PCFSoftShadowMap
Three.js uses PCFShadowMap as the default.
Baking shadows
A good alternative to using Three.js shadows is to bake the shadows similar to baking the lights. The problem is that they only work for non dynamic scenes where the objects don't change there position or rotation.
Another more dynamic way is to bake a shadow and then set it as a material for a plane that lies a little bit over the ground plane. If the object then comes close to the ground we set the opacity of that material to high and if it far from ground we set it to low
const sphereShadow = new THREE.Mesh(
new THREE.PlaneGeometry(1.5, 1.5),
new THREE.MeshBasicMaterial({
color: 0x000000,
transparent: true,
alphaMap: simpleShadow
})
)
...
sphereShadow.position.y = plane.position.y + 0.01
sphereShadow.material.opacity = (1 - sphere.position.y) * 0.3
See more at the end of this Site
Optimizations
One Instance of material and geometry
Use one material and one geometry for multiple meshes. If you create a loop to create multiple meshes set the material and the geometry outside
const material = new THREE.MeshMatcapMaterial({matcap:matcapTexture});
const geo = new THREE.BoxGeometry(1,1,1);
for(let i = 0; i<100;i++){
const mesh = new THREE.Mesh(geo,material);
}
Disposing unused instances
To improve the performance and avoid memory leaks we should dispose unused Three.js library entities. Whenever we create an instance of a three.js type, certain amount of memory gets allocated.
Free up our memory of unused instances of three.js types we can use the .dispose() method.
myMaterial.dispose()
myGeo.dispose()
scene.remove(Mesh/Points)
Realistic Render
The goal is to render as realistic as possible.
For environmentmap try to use the smallest possible texture - especially if you don't use it as a background.
Tone mapping
Tone mapping is a technique where Three.js fakes the process of converting low dynamic range(LDR) values to high dynamic range(HDR) values.
renderer.toneMapping = THREE.NoToneMapping(default)
Possible values that we can use are:
THREE.LinearToneMapping
THREE.ReinhardToneMapping - settings similar to a camera with improper settings.
THREE.CineonToneMapping
THREE.ACESFilmicToneMapping
To influence the amount of light that we want to allow in the scene we can adjust the expose of the tone mapping.
renderer.toneMappingExposure = 3
Antialiasing
Aliasing happens because the renderer tests what geometry is being rendered in that currently rendered pixel. Because the edges of the geometry are not aligned with the vertical and horizontal particle grid the geometry seems to be pixelated because every pixel just can have one color.
One solution is to increase the resolution of the renderer and render the scene at a much higher resolution than needed and then shrinking it down. This is called Super Sampling Anti-Aliasing(SSAA). - Render everything at 2x the size - Resize it back down to normal size - Final image is smoother because each pixel is average of 4 higher-resolution pixels
This leads to a better quality but also is heavy on the performance.
Another way is Multi Sampling Anti-Alisaing which just applies the anti-aliasing to the edges of the object, where jaggedness is most visible. - Only samples multiple points on the geometry edges - Blends samples to produce smoother edges. Like only smoothing out the lines of a drawing without touching the inside or the background.
This is much faster than SSAA but doesn't work well with certain effects like post-processing shaders or transparent objects.
We can activate MSAA by setting renderer.antialias:true in the `WebGLRenderer.
Because screens with a pixel ratio above 1 don't need antialiasing it can make sense to only allow antialiasing when the screen pixel ratio is below 2.
Shadow
To create realistic shadows when we are using environmentmap we need to add a light in the scene that is similar to the lighting of the environmentmap.
Then activate shows in the renderer
renderer.shadowMap.enabled=true
renderer.shadowMap.type = THREE.PCFSoftShadowMap
directionalLight.castShadow = true
When we enable shadows for a directionalLight Three.js uses an orthographic camera to render the shadow map - a black and white picture of what the light sees.
For that camera we also can set the near and far values - they define how close or far objects can be form the light to cast shadows.
So we can reduce the default value of far
directionalLight.shadow.camera.far = 20
So only object between 1 and 20 units away from the light should cast shadows.
To increase the quality of the shadows we also can increase the shadow map to something like 1024x1024.
directionalLight.shadow.mapSize.set(1024,1024)
Also play with smaller resolutions if you get good enough results and can improve your performance.
To activate shadows in all materials of the loaded object we can create a function updateAllMaterials that activates the shadows in each material and call it when the model got loaded.
const updateAllMaterials = () => {
//
scene.traverse((child) => {
if(child.isMesh){
child.castShadow = true
child.receiveShadow = true
}
})
}
traverse() is a build in Three.js function that loops through the entire hierachy of the scene and all objects in scene graph - including children, grandchildren etc.
Especially when you use your own created models it can happen that you get shadow acne. It means the shape is casting a shadow on its own surface. It can happen when calculating if the surface is in the shadow or not.
To fix that we have to change the bias and normalBias of the shadow.
bias - helps for flat the surfaces
normalBias - helps for rounded surfaces
Play with the values and debug.ui to find the right values.
Textures and color space
You can get good textures at Polyhaven
Here are some exemplary settings:
Color space defines how color values are intepreted - especially brighness.
But humans don't see brighness linearly - because we are more sensitive to darker tones than lighter ones. Often images are stored in a non-linear color space called sRGB.
Three.js uses two color spaces:
- THREE.LinearSRGBColorSpace - Default color space used for math,lighting,shaders etc
- THREE.SRGBColorSpace - used for textures meant to be seen(albedo/diffuse/color maps)
So we can split textures into two categories:
- Visual textures
- Color textures -> texture.colorSpace = THREE.SRGBColorSpace
- Data textures -
- Non color information
- normal textures
- roughness texture -> should stay in linear space
- ambientocculusion texture
Add Gizmo to object
With TransformControls you can add a gizmo to an object so you can move an object.
DragControls allows you to move an object ona plane facing the camera by drag and drop them.
Interactions
Raycaster
A Raycaster shoots a ray in a specific direction and checks if it hits any objects or any object intersects with it. This allows us for example to detect if the camera/player is facing a specific object or something is currently under the mouse and more.
Raycaster work on Meshes and on Groups because the raycaster checks by default the children and the children of children of the object.
To create a raycaster we call
const raycaster = new THREE.Raycaster();
With the .set(postion,direction) method we can set the position and direction of the Raycaster
const rayCaster = new THREE.Raycaster();
const rayOrigin = new THREE.Vector3(-3,0,0);
const rayDirection = new THREE.Vector3(10,0,0);
rayDirection.normalize()
rayCaster.set(rayOrigin,rayDirection);
To detect the objects that lay in the ray we can useintersectObject() and intersectObjects().
const intersectObject = rayCaster.intersectObject(objectX)
const intersectObjects = rayCaster.intersectObjects([objectX,objectY,objectZ]);
By setting the second parameter to false we can set that the raycaster doesn't check for collisions with the children of the object.
const intersectObject = rayCaster.intersectObject(objectX,false)
We always get back an Array as the result of the intersectObject/s functions because a ray can go through an object mulitple times.
The information that we get returned are:
distance- distance between origin of ray and collision pointface- what face of the geometry got hit by the rayfaceIndex- index of faceobject- what is object of the collisionpoint-Vector3of exact position in 3D space of the collisionuv- UV coordinates in the geometry
To test if there is an object in front of the player we can use distance.
To change the color of an object we can manipulate the object.
To trigger an explosion at the impact point of the ray we can use point.
To test if moving objects hit a raycast we need to execute the test every frame.
...
const clock = new THREE.Clock()
const tick = () => {
const elapsedTime = clock.getElapsedTime();
const rayOrigin = new THREE.Vector3(-3,0,0);
const rayDirection = new THREE.Vector(1,0,0);
rayDirection.normalize();
rayCaster.set(rayOrigin,rayDirection);
const objectsToTest = [object1,object2,object3]
const intersects = rayCaster.intersectObjects(objectsToTest);
for(const object of objectsToTest){
object.material.color.set('#00ff00')
}
for(const intersect of intersects){
intersect.object.material.color.set('#ff0022')
}
object1.position.y = Math.sin(elapsedTime *0.3) * 1.5;
object2.position.y = Math.sin(elapsedTime *0.6) * 1.5;
object3.position.y = Math.sin(elapsedTime *0.4) * 1.5;
}
Raycaster with mouse
Hovering
To evaluate if the mouse is hovering an object we need to get the position of the mouse.
We want the value range from -1 to 1 on the vertical and the horizontal with the vertical value being postivie when the mouse is up.
const cursor = new THREE.Vector2();
window.addEventListener("mousemove",(event)=> {
cursor.x = event.clientX/sizes.width * 2 -1;
cursor.y = -(event.clientY/sizes.height) * 2 +1;
});
// Recommended to cast the ray in the tick because in some browser casting in the eventlistener could trigger it multiple times
const tick = () => {
//To point the ray in the right direction
rayCaster.setFromCamera(mouse,camera);
const objectsToIntersect = [object1,object2,object]
const intersects = rayCaster.intersectObjects(objectsToIntersect);
//Set object to blue
for(const intersect of intersects){
intersect.object.material.color.set('#0000ff')
}
//Set to red
for(const object of objectsToIntersect){
if(!intersects.find(intersect=>intersect.object === object)){
object.material.color.set('#00ff00')
}
}
}
Mouse Enter Mouse Leave
To see if the mouse enters or leaves an area or an object we can create a variable that tracks if the object still intersects or not. We then set and reset it in tick()
let currIntersect = null;
const tick = () => {
raycaster.setFromCamera(mouse,camera);
const objectsToIntersect = [object1,object2,object3]
const intersects = raycaster.intersectObjects(objectsToIntersect)
//if intersects.length = 0 -> false
if(intersects.length){
if(!currentIntersect){
console.log('mouse enter');
}
currIntersect = intersect[0]
} else {
if(currIntersect){
console.log('mouse leave')
}
currIntersect = null
}
}
window.addEventListener('click', () => {
if(currIntersect){
console.log("click")
switch(currIntersect.object){
case object1:
console.log("obj 1");
break;
case object2:
console.log("obj 2");
break;
case object3:
console.log("obj 3");
break;
}
}
})
Mouse Movement
We can use the mouse to set the position of our camera and let the camera always look at the object.
To get the mouse position we listen to the JS event mousemove with the addEventListener
const camera = new THREE.PerspectiveCamera(75,window.innerWidth/window.innerHeight,1,100);
camera.position.z = 10
camera.lookAt(mesh.position);
scene.add(camera);
Doing full rotation around object
By using Math.PI we can map the mouse position onto a specific angle on the circle. So we translate the camera on a circle shape around the object and let it look at the object.
const radius = 2;
camera.position.x = Math.sin(Math.PI * 2 *cursor.x)*radius;
camera.position.z = Math.cos(Math.PI *2 * cursor.x)*radius;
camera.position.y = cursor.x * 2;
camera.lookAt(mesh.position)
Scrolling
Scroll Along a Path
// First define your variables
let scrollTotal = 0;
const scrollSpeed = 0.1;
const scrollMin = 0;
const scrollMax = 500;
let scrollPathPos = 0;
// Define the function first
const handleWheel = (event) => {
event.preventDefault();
const deltaY = event.deltaY || event.detail || -event.wheelDelta;
// Update total scroll
scrollTotal += deltaY * scrollSpeed;
if (scrollTotal < 0) scrollTotal = 0;
// Clamp the TOTAL scroll value
const clampedScroll = Math.max(
scrollMin,
Math.min(scrollMax, scrollTotal)
);
// Map from scroll range to 0-1 range
scrollPathPos = (clampedScroll - scrollMin) / (scrollMax - scrollMin);
const pathT = Math.min(1, Math.max(0, scrollPathPos));
console.log(pathT);
const camPos = path.getPointAt(pathT);
camera.position.copy(camPos);
const tangent = path.getTangentAt(pathT).normalize();
camera.lookAt(camPos.clone().add(tangent));
};
// Then add the event listener
const domElement = renderer.domElement;
domElement.addEventListener("wheel", handleWheel, { passive: false });
Scroll Elements top to bottom
The idea is that we position of objects on different y axis in the scene and then make the camera scroll with the
scroll event.
For the html elements you need to wrap them in <section>
//Position objects
const objectDistance = 4
mesh1.position.y = - objectsDistance * 0
mesh2.position.y = - objectsDistance * 1
mesh3.position.y = - objectsDistance * 2
To get the scroll value we can get window.scrollY. This value contains the amount of pixels that have been scrolled. This number can get quite big. To show only one element per viewport section we can divide the scrolling value with the height of the viewport.
window.innerHeight
let scrollY = window.scrollY
window.addEventListener('scroll',()=> {
scrollY = window.scrollY
})
const tick = () => {
// Scroll Y is positive when scrolling down so we need to invert it.
//If the user scrolls down one section, the camera moves down to the next object
camera.position.y = - scrollY/window.innerHeight * objectDistance
}
Parallax
To make the experience more immersive and intresting we can add a parallax effect by additionally moving the objects according to the mouse.
const cursor = {}
cursor.x = 0;
cursor.y = 0;
window.addEventListener("mousemove",()=>{
//Pixel position of the mouse
// Normalise these values so users with different viewports have the same experience
cursor.x = event.clientX/window.innerWidth - 0.5;
cursor.y = event.clientY/window.innerHeight - 0.5 ;
})
const tick = ()=> {
const paralaxX = cursor.x;
const paralaxY = - cursor.y;
camera.position.x = parallaxX;
camera.position.y = parallaxY;
}
The problem is when we apply the mouse position to the camera the scroll effect doesn't work anymore. Because the scroll gets overwritten. To solve the problem we add the camera to a group and then apply the parallax effect to the group not the camera itself.
const camGroup = new THREE.Group();
scene.add(camGroup)
const camera = new THREE.PerspectiveCamera(35,window.innerWidth/window.innerHeight,0.1,100);
camera.position.z = 6;
cameraGroup.add(camera);
...
const tick = () => {
// Animate camera
camera.position.y = - scrollY / sizes.height * objectsDistance
const paralaxX = cursor.x;
const paralaxY = -cursor.y;
camGroup.position.x = parallaxX;
camGroup.position.y = parallaxY;
}
Easing
To make the experience even smoother we should apply some easing. The idea is that on each frame instead of lineally moving straight to the target we move a fraction of the total distance like 1/20th closer to the target. So every frame the camera gets closer to the target and the fraction of the distance smaller so - so first the camera moves faster and the closer it gets to the target the slower it moves.
To again assure this works on every device the same way we need to multiply it with the time between the current frame and the previous frame
const clock = new THREE.Clock();
let previousTime = 0;
const tick = () => {
const elapsedTimes = clock.getElapsedTime();
const deltaTime = elapsedTime - previousTime;
previousTime = elapsedTime;
}
//parallaxX -cameraGroup.postion calculates the distance
cameraGroup.position.x += (parallaxX-cameraGroup.position.x)*deltaTime*5;
cameraGroup.position.y += (parallaxY-cameraGroup.postion.y)*deltaTime*5;
Trigger animations
To trigger animations when we reach a section we can create a currentSection variable and set it to the scrollY/window.innerHeight. This create an index value with Math.round()
let scrollY = window.scrollY
let currentSection = 0;
window.addEventListener('scroll',()=>{
scrollY = window.scrollY;
const newSection = Math.round(scrollY/window.innerHeight);
if(newsection != currentSection){
currentSection = newSection;
gsap.to(
sectionMeshes[currentSection].rotation,
{
duration:1.5,
ease:'power2.inOut',
x: '+=6',
y: '+=3'
z: '+=1.5'
}
)
}
})
const tick = () => {
...
for(const mesh of sectionMeshes){
mesh.rotation.x += deltaTime*0.1
mesh.rotation.y += deltaTime*0.12
}
}
Physics
Physics help to make the experience of your website more playful. To get realistic physics with tension, friction, bouncing etc it makes sense to use a library instead of writing all your own physics.
Theory
To have physics in our Three.js scene we need to create a physics world where the laws of physics rule. But we can't see it. It is theoretical. We create our mesh in the Three.js scene and also create a version of that mesh in the physics world. On each frame before the rendering happens we tell the physics world to update itself. We then take the values from the objects in the phyics world and assign them to the Three.js objects.
Libraries
3D
Ammo.js
Website A can be quite heavy Still updated by community Mostly used. Three.js examples.
Cannon.js
Website Lighter than Ammo.js and easier to implement.
To install cannon.js npm install cannon and then import CANNON from 'cannon'
There is also a library that is based on cannon but actually still get's updated. It is called Cannon-es
npm install cannon-es
To create a physics world we use new CANNON.Wolrd()
const world = new CANNON.World()
To add gravity we set a Vec3
cannon.gravity.set(0,-9.82,0)
When we want to add shapes the the physics world we need to add Body. It is a an object that will fall and collide with other bodies. But before that we decide which shape the body should take
...
const sphreShape = new CANNON.Sphere(0.5)
const sphereBody = new CANNON.Body({
mass:1,
position: new CANNON.Vec3(0,3,0),
shape: sphereShape
})
//Adding body to the world
world.addBody(sphereBody)
To update the physics world we need to use the step()function. How it works gets described here:Timesteps.
The .step() function expects a fixed time step. For 60 FPS we give it a value of 1/60.
For the number of iterations we can use a value like 3.
For delta time we use the clock and calculate the delta time with elapsedTime
const clock = new THREE.Clock();
let oldElapsedTime = 0
const tick = () => {
const elapsedTime = clock.getElapsedTime();
const deltaTime = elapsedTime-oldElapsedTime;
oldElapsedTime = elapsedTime;
world.setp(1/60,deltaTime,3);
}
What is missing now is that we need to assign the values from the sphereBody to the shape in three.js
sphere.position.x = sphereBody.position.x
sphere.position.y = sphereBody.position.y
sphere.position.z = sphereBody.position.z
OR
sphere.position.copy(sphereBody.position);
To make objects interact/react to each other all the object need to bodies in the physics world.
Adding Box
A Box Body in Cannon has a different messure than in Three.js.
It needs a halfExtents which is a Vec3 and represents a segment from the center of the box to the box corners.
const boxShape = new CANNON.Box(new CANNON.Vec3(width*0.5,height*0.5,depth*0.5));
const boxBody = new CANNON.Body({
mass:1,
position:new CANNON.Vec3(0,1,0);
shape:boxShape,
material:defaultMaterial
})
world.addBody(boxBody)
Static Body
If you want an object to be static, so not affected by gravity we can set mass = 0
You also can first create your shape and body and then assign the properties
const plane = CANNON.Plane()
const planeBody = CANNON.Body();
planeBody.mass = 0
planeBody.addShape(plane);
world.add(planeBody);
// To rotate we use quaternion in CANNON
planeBody.quaternion.setFromAxisAngle(new CANNON.Vec3(-1,0,0),Math.PI*0.5);
In Cannon we can also create a Body and add multiple Shapes for example for complex but solid shapes.
Contact Material
To affect how different bodies react with each other we can set a Cannon ContactMaterial and Material. So we create a material for each type of material we have in our scene.
The default material is plastic. We can write both default or plastic for that material.
const plasticMat = new CANNON.Material('plastic')
For the interaction between the materials in the scene we also have to create a ContactMaterial that defines how these two materials react to each other.
const plasticMaterial = new CANNON.Material('plastic');
const concreteMaterial = new CANNON.Material('concrete');
const plasticConcreteContactMaterial = new CANNON.ContactMaterial(
concreteMaterial,
plasticMaterial,
{
friction:0.1,//How much does it rub - default value 0.3
restitution:0.7// how much does it bounce - default value 0.3
}
)
world.addContactMaterial(plasticConcreteContactMaterial);
We also then have to assign these physics materials to the bodies
const sphereBody = new CANNON.Body({
...
material:plasticMaterial
})
planeBody.material = concreteMaterial;
or delete the assigning for each material and just set the contact material for the world
world.defaultContactMaterial = defaultContactMaterial
Applying forces
There are multiple ways to apply different forces in CANNON:
applyForceto apply a force from specific point in space:- wind
- small sudden push on domino
- greate sudden force like a jump
applyImpulsesimilar toapplyForceapplies directly to the velocity-
applyLocalForcesame asapplyForcebut coordinates are local to the body(0,0,0) center of the body -
to apply a small impulse
sphereBody.applyLocalForce(new CANNON.Vec3(150,0,0), new CANNON.Vec3(0,0,0)) -
applyLocalImpulseis the same asapplyImpulsebut the coordinates are local to the Body.
Applying wind
Because the wind force is happening every frame we apply these force in tick()
const tick = () => {
...
sphereBodey.applyForce(new CANNON.Vec3(-0.5,0,0), sphereBody.position);
...
world.step(1/60,deltaTime,3);
...
}
Multiple Objects
When we handle multiple objects first it makes sense to create functions that handle the THREE.js mesh and the CANNON.Body creation in one function. Second we create an array where we add the created objects so we can change them later
const objectsToUpdate = [];
const createSphere = (position,radius) => {
const sphereMesh = new THREE.Mesh()
const sphereGeo = new THREE.SphereGeometry(radius,20,20);
const sphereMat = new THREE.MeshStandardMaterial({
metalness:0.3,
roughness:0.4,
envMap:environmentMapTexture,
envMapIntensity:0.5
})
sphereMesh.add(sphereGeo,sphereMat);
sphereMesh.castShadow = true;
sphereMesh.position.set(position);
scene.add(sphereMesh);
const sphereShape = new CANNON.Sphere(radius);
const sphereBody = new CANNON.Body({
mass:1,
position: position,
shape:sphreShape,
material:defaultMaterial
}
)
world.addBody(body);
objectsToUpdate.push({
mesh:sphereMesh,
body:sphereBody
})
}
const tick = () => {
...
world.step(1/60,deltaTime,3);
for(const obj in objectsToUpdate){
//Assign position of physics body to the threejs mesh
obj.mesh.position.copy(obj.body.position);
//Copy the rotation
obj.mesh.quaternion.copy(obj.body.quaternion);
}
}
Events
We can listen and use events to execute some logic for our scene.
Event we can listen to are colide, sleep,wakeup
body.addEventListener('collide', playSound)
const playSound = (collision) => {
//Resetting time of sound so if another sound is playing it starts again from the start.
sound.currentTime = 0;
sound.play()
}
We also get from the event the strength of the collision with collision.contact.getImpactVelocityAlongNormal() which we then can use to determine some logic.
When you remove bodies from the scene don't forget to remove also the eventlistener
body.removeEventListener('collide',playSound)
Constrains
CANNON has different constrains to create certain behavior:
HingeConstraintDoorhinge behaviourDistanceConstraintBodies are forced to keep distance between each otherLockContraintmergin bodiesPointToPointConstraintgluying body to specifc point
Performance
Removing Elements
To remove Bodies from the world we can use world.removeBody(obj.body)
Broadphase
To assure a good performance of your scene you don't want to calculcate every Body against all other Bodies.
The goal is to just process the bodies that are actually close to each other and react with each other.
For that CANNON has Broadphase with different algorithms to presorts the Bodies before it processes the calculations:
NaiveBroadphase: Actually tests all theBodiesagainst each other(default).GridBroadphase: Splits up the world into girdcells and only tests theBodiesthat are in the same or the neighbors gridcell.SAPBroadphase: TestBodieson arbitrary axes during multiple steps(recommendet).
world.broadphase = new CANNON.SAPBroadphase(world);
Sleep
Even if the Body stays still it gets tested by Broadphase. To avoid that we can put the object into sleep if the
Body's velocity is really low until a force is applied to it or a collision happens.
world.allowSleep = true
With sleepSpeedLimit and sleepTimeLimitwe can define thresholds to the sleep behaviour
Workers
Workes allow you to put part of your code on a different thread to improve performance. But that code has to be seperated as you can see here Worker Example;
Further information here
Oimo.js
Website Lighter than Ammo.js and also easier
Rapier
Website Good performance Currently maintained
2D
Matter.js
Website Still kind of updated
P2.js
[Website:] (https://schteppe.github.io/p2.js/) Hasn't been update for 2 years
Planck.js
Box2D.js
[Website:] (http://kripken.github.io/box2d.js/demo/webgl/box2d.html)
Color class
Set color of a material
object.material.color.set('#ff0000')
Mix Colors
We can use the color1.lerp(color2,alpha) function to mix two colors
Vector3 class
Set Vector
mesh.position.set(0.2,0.7,0.3)3
Get the length of the position vector
mesh.position.length()
Get the distance from another Vector
mesh.position.distanceTo(camera.position)
Normalize Length of Vector
mesh.position.normalize()
Debug UI
There are multiple libraries to create some Debug UIs. The most popular like dat.GUI or control-panel controlkit guify oui
Dat.GUI
Implementation
Installation
npm install --save dat.gui
Import
import * as dat from 'dat.gui'
Instantiation
const gui = new dat.GUI
Elements
Range - numbeers with minimum and maximum value
Color - for various color formats
Text - Simple Text
Checkbox - for booleans
Select - Choice from list of values
Button - to trigger functions
Folder - to organize panel with lot of elements
Add Elements
We add elements with gui.add(object,property of object) to add elements to the GUI.
gui.add(mesh.position, 'y')
Specifying ranges and steps
gui.add(mesh.position,'y',-3,3,0.01)
or use methods from dat.GUI.
gui.add(mesh.position,'y').min(-3).max(3).step(0.01).name('elevation')
Set Element visible via GUI
gui.add(mesh,'visible')
Drop-down
To create a drop down we add an object with key value pairs to it
Colors
Define object with color as its property
const parameters = { color: 0xff0000}
Add object
gui.addColor(parameters,'color')
Signaling changes of property in Dat.GUI properts and setting property in three.js
const parameters = {
color:0xff0000
}
gui.addColor(parameters,'color')
.onChange(()=> {
material.color.set(parameters.color)
})
const material = new THREE.MeshBasicMaterial({color:parameters.color})
Update Values
If we want to show and update the values in our scene we have to call .onChange()
Trigger a function
To trigger a function we have to add the function again like with colors to an object.
import gsap from 'gsap'
...
const parameters = {
color,0xff0000,
spin: () => {
gsap.to(mesh.rotation,{duration:1, y:mesh.rotation.y +Math.PI*2})
}
}
gui.add(parameters, 'spin')
If you want to trigger a function which also needs parameters we can create an object for that
const gui = new GUI();
const debugObject = {}
debugObject.createSphere = () => {
createSphere(0.5,{x:0,y:2,x:1})
}
gui.add(debugObject,'createSphere')
Hide Panel
We can press H to hide the panel
or set it hidden from beginning
gui.hide()
Close Panel
To have your GUI closed at the beginning
const gui = new dat.GUI({closed:true})
Set Width of Panel
const gui = new dat.GUI({width:400})
More infos under dat.GUI API
Show window to control and change properties of the objects
const pane = new Pane()
pane.addInput(material, 'shininess',{
min:0,
max:100,
step:1
})
// passing two objects
pane.addInput(grassTexture, 'offset', {
x: {
min:0,
max:1,
step:0.001
},
y: {
min:0,
max:1,
step:0.001
}
})
Vite Config file
export default {
root: 'src/',//Where are we serving up our experience
publicDir: '../static/',//We are hosting our static assets in the static folder
base: './',
}
Math functions
PI: Math.PI
SINE: Math.sin()
create random angles
const angle = Math.Random() * Math.PI *2;
Code Structure for bigger projects
== TO JAVASCRIPT BASICS LATER ==
Modules
Modules allow us to seperate our code into multiple files and then import them when needed
import test from './test.js'
Modules can export one or multiple things.
export default 'Hello World, this is my first module'
In the other script
It's important that for our own modules we need to add ./ before the file otherwise JS tries to find it in the node_modules
Export a function To export a function
Export objectconst object = {
me:"Hallo world"
}
const printMe = ()=> {
console.log("me")
}
//Export one object
export default object;
//Or export multiple
export default {object,printMe}
import {object,printMe} from './test.js'
console.log(object)
printMe()
Classes
Classes in JS allow to use Object-oriented Programming
To create a class
class MyClass{}
By convention classes are written in PascalCase starting with a capital letter.
Classes are blueprints to create an object. We then can use that blueprint to create multiple objects.
To create an instance of the the class
const classInstance = new MyClass()
Functions inside a class
Classes have a constructor method that get's called when the class got instantiated
class MyClass{
constructor(name,age){
this.name = name
this.age = age
console.log(`I'm ${this.name} and I'm alive`)
this.doThis();
}
doThis(){
console.log(`And now ${this.name} do this`)
}
}
const classInstance = new MyClass("MyName")
console.log(classInstance.age)
Inheritance
Classes allow us to let a class inherit from a parent class. So we can create a Parent class and then let a Child class inherit behaviour and values from the Parent
import ParentClass from './ParentClass.js'
class ChildClass extends ParentClass
{
childBehaviour1(){
console.log(`${this.name} is hungry but can't make dinner on his own`)
}
//Methods in the Childclass with the same name like the parent will overwrite the parent class
doThis(){
console.log(`now a child does this`)
}
}
If you want the Child class to have a different constructor or you want to extent the Parent constructor in the Child class we need to callsuper()
import ParentClass from './ParentClass.js'
class ChildClass extends ParentClass{
constructor(name,age){
//super basically calls the constructor of the parent class
super(name,age);
this.canEat = false
//you could even call the method from the parent class but this can make the code complicated
super.doThis()
}
}
Structuring Code
So the idea is to seperate the code into different files and export in each file a class .
A good practise is to put the whole three.js experience into its own Experience class.
export default class Experience{
constructor(){
console.log("Welcome to my experience")
}
}
import Experience from './Experience.js'
const experience = new Experience();
It makes sense to send the canvas as a parameter into the class
export default class Experience {
constructor(canvas){
this.canvas = canvas;
}
}
...
const experience = new Experience(document.getSelector('canvas'))
export default class Experience {
constructor(canvas){
this.canvas = canvas;
//CAREFUL WITH MULTIPLE EXPERIENCES THIS OVERWRITES THEM
window.experience = this//This gives us the window object
}
}
It always can make sense to have some Util classes saved that you can use in different projects.
export default class Sizes {
constructor(){
this.width = window.innerWidth;
this.height=window.innerHeight;
this.pixelRatio = Math.min(window.devicePixelRatio,2);
window.addEventListener("resize",()=>{
this.width = window.innerWidth;
this.height = window.innerHeight;
this.pixelRatio = Math.min(window.devicePixelRatio,2);
})
}
}
...
import Sizes from './Utils/Sizes.js'
export default class Experience {
constructor(canvas){
this.sizes = new Sizes();
console.log(this.sizes.width)
console.log(this.sizes.height)
console.log(this.sizes.pixelRatio)
}
}
Event Emitter
To enable the class to emit events it needs to inherit from a EventEmitter class.
// This class lets you create and manage custom events.
// You can "listen" to events with `on()`, stop listening with `off()`, and "trigger" events with `trigger()`.
export default class EventEmitter {
constructor() {
// Create an object to store all the event listeners (callbacks)
this.callbacks = {}
// Add a default "base" namespace to organize events
this.callbacks.base = {}
}
/**
* Start listening to events.
*
* @param _eventNames - The name(s) of the events to listen for (e.g. 'click', 'hover.menu')
* @param callback - The function to run when the event is triggered
*/
on(_eventNames, callback) {
// Check if event names or callback are missing
if (typeof _eventNames === 'undefined' || _eventNames === '') {
console.warn('wrong names')
return false
}
if (typeof callback === 'undefined') {
console.warn('wrong callback')
return false
}
// Clean up and split the string of event names into an array
const eventNames = this.resolveNames(_eventNames)
// Go through each event name in the list
eventNames.forEach((eventName) => {
// Separate the event name and namespace (e.g. 'hover.menu' → value: 'hover', namespace: 'menu')
const _eventName = this.resolveName(eventName)
// If the namespace doesn’t exist yet, create it
if (!(this.callbacks[_eventName.namespace] instanceof Object))
this.callbacks[_eventName.namespace] = {}
// If this specific event name doesn’t exist yet, create an empty list to store all the functions that listen to event
//If there is no list of callbacks yet for this specific event, create an empty one."
if (!(this.callbacks[_eventName.namespace][_eventName.value] instanceof Array))
this.callbacks[_eventName.namespace][_eventName.value] = []
// Add the callback function to this event
this.callbacks[_eventName.namespace][_eventName.value].push(callback)
})
// Allow method chaining (e.g. emitter.on(...).on(...))
return this
}
/**
* Stop listening to one or more events.
*
* @param eventNames - One or more event names to remove (e.g. 'click', 'hover.menu', 'menu.')
*/
off(eventNames) {
// Check if input is missing
if (typeof eventNames === 'undefined' || eventNames === '') {
console.warn('wrong name')
return false
}
// Clean up and split the string of event names into an array
const _eventNames = this.resolveNames(eventNames)
// Go through each event name
_eventNames.forEach((eventName) => {
const _eventName = this.resolveName(eventName)
// If only a namespace was provided (e.g. 'menu.'), remove the entire namespace
if (_eventName.namespace !== 'base' && _eventName.value === '') {
delete this.callbacks[_eventName.namespace]
}
// Otherwise, remove a specific event in one or all namespaces
else {
// If no namespace is specified, try to remove the event from every namespace
if (_eventName.namespace === 'base') {
for (const namespace in this.callbacks) {
if (
this.callbacks[namespace] instanceof Object &&
this.callbacks[namespace][_eventName.value] instanceof Array
) {
// Delete this event from the namespace
delete this.callbacks[namespace][_eventName.value]
// If the namespace is now empty, delete it too
if (Object.keys(this.callbacks[namespace]).length === 0)
delete this.callbacks[namespace]
}
}
}
// If a specific namespace is given, remove only from that one
else if (
this.callbacks[_eventName.namespace] instanceof Object &&
this.callbacks[_eventName.namespace][_eventName.value] instanceof Array
) {
delete this.callbacks[_eventName.namespace][_eventName.value]
// Remove namespace if empty
if (Object.keys(this.callbacks[_eventName.namespace]).length === 0)
delete this.callbacks[_eventName.namespace]
}
}
})
return this
}
/**
* Trigger (fire) an event so that all the functions listening to it will run.
*
* @param _eventName - The name of the event to trigger
* @param _args - Optional array of arguments to pass to the callback functions
*/
trigger(_eventName, _args) {
// Check if name is missing
if (typeof _eventName === 'undefined' || _eventName === '') {
console.warn('wrong name')
return false
}
let finalResult = null
let result = null
// Make sure _args is an array, or use an empty array if none provided
const args = !(_args instanceof Array) ? [] : _args
// Clean and resolve the event name
let name = this.resolveNames(_eventName)
name = this.resolveName(name[0]) // Only take the first resolved name
// If no specific namespace is given
if (name.namespace === 'base') {
// Look for the event in every namespace
for (const namespace in this.callbacks) {
if (
this.callbacks[namespace] instanceof Object &&
this.callbacks[namespace][name.value] instanceof Array
) {
// Call every function attached to this event
this.callbacks[namespace][name.value].forEach(function(callback) {
result = callback.apply(this, args)
// Store the first result returned
if (typeof finalResult === 'undefined') {
finalResult = result
}
})
}
}
}
// If a specific namespace is given
else if (this.callbacks[name.namespace] instanceof Object) {
if (name.value === '') {
console.warn('wrong name')
return this
}
// Call every function attached to this event in the given namespace
this.callbacks[name.namespace][name.value].forEach(function(callback) {
result = callback.apply(this, args)
// Store the first result
if (typeof finalResult === 'undefined')
finalResult = result
})
}
return finalResult
}
/**
* Helper function that cleans and splits event name strings.
*
* Example: 'click, move.menu' → ['click', 'move.menu']
*/
resolveNames(_eventNames) {
let names = _eventNames
// Remove weird characters except letters, numbers, commas, slashes, and dots
names = names.replace(/[^a-zA-Z0-9 ,/.]/g, '')
// Convert commas and slashes to spaces
names = names.replace(/[,/]+/g, ' ')
// Split by space into an array
names = names.split(' ')
return names
}
/**
* Helper function that splits a name like 'move.menu' into:
* {
* original: 'move.menu',
* value: 'move',
* namespace: 'menu'
* }
*/
resolveName(name) {
const newName = {}
const parts = name.split('.')
newName.original = name
newName.value = parts[0] // The event name (e.g. 'move')
newName.namespace = 'base' // Default to 'base' if no namespace is given
// If there's a namespace, use it
if (parts.length > 1 && parts[1] !== '') {
newName.namespace = parts[1]
}
return newName
}
}
Now we can let the Sizes class inherit from the Event
import EventEmitter from '/EventEmitter.js'
export default class Sizes extends EventEmitter
{
constructor(){
super()
window.addEventListener('resize',()=> {
//we trigger from inside the Sizes class
this.trigger('resize')
})
}
}
import Sizes from '/Utils/Sizes.js'
export default class Experience {
constructor(canvas){
window.experience = this;
this.canvas = canvas
this.sizes = new Sizes()
//Listen to the event from outside
this.sizes.on('resize',()=>{
this.resize()
})
}
resize(){
console.log("Window resize happended")
}
}
Time
A Time class can be useful to store values like currentTime,deltaTime
import EventEmitter from '/EventEmitter.js'
export default class Time extends EventEmitter
{
constructor(){
super()
this.start = Date.now() // Starttime of experience
this.current = this.start // currenttimestand that changes each frame
this.elapsed = 0 // how much time was spent since start of experience
this.delta = 16 // how much time was spent since preivous frame - 16 is close to how many milliseconds there ibetween two frames at 60fps
//To avoid delta = 0 on first frame we call window.requestAnimation here
window.requestAnimationFrame(()=> {
this.tick()
})
}
tick(){
const currentTime = Date.now()
this.delta = currenTime - this.current
this.current = currentTime;
this.elapsed = this.current - this.start
this.trigger('tick')
console.log('tick')
window.requestAnimationFrame(()=>{
this.tick()
})
}
}
...
import Time from '/Utils/Time.js'
export default class Experience{
constructor(canvas){
...
this.time.on('tick',()=>{
this.update()
})
}
update(){
}
}
Import Three.js with Camera,etc
To handle the camera seprately we can create its own class for it
import * as THREE from 'three'
...
export default class Experience{
constructor(canvas){
//...
this.sizes = new Sizes()
this.time = new Time()
this.scene = new THREE.Scene()
this.camera = new Camera()
}
}
Camera class we need to access properties from other classes like Sizes and maybe Time.
Ways to access values and properties from the Experience class from the camera
- (1) Global variable
- (2) Sending parameters
- (3) using singleton
(1)
With window.experience = this we add the experience as a global object to the window which makes experience accessible everywhere in the code.
export default class Camera
{
constructor(){
this.experience = window.experience
console.log(this.experience)
}
}
export default class Experience{
constructor(canvas){
...
//this == experience instance
this.camera = new Camera(this)
...
}
}
export default class Camera
{
constructor(experience){
this.experience = experience
}
}
one instance of something. And everytime we create a new instance of the same thing it references to the first created instance.
let instance = null
export default class Experience
{
constructor(canvas){
if(instance){
//if instance already contains something leave the function
return instance
}
//if instance is still null assign this instance experience to instance
instance = this
}
resize(){
this.camera.resize()
}
}
export default class Camera
{
constructor(){
this.experience = new Experience()
// from the experience class we get the sizes
this.sizes = this.experience.sizes
this.scene = this.experience.scene
this.canvas = this.experience.canvas
this.setCamInstance()
this.setOrbitInstance()
}
setCamInstance(){
this.camInstance = new THREE.PerspectiveCamera(35,this.sizes.width/this.sizes.height, 0.1,100)
this.camInstance.position.set(3,4,5)
this.scene.add(this.camInstance)
}
setOrbitInstance(){
this.controls = new OrbitControls(this.camInstance,this.canvas)
this.controls.enableDamping = true;
}
resize(){
this.camInstance.aspect = this.sizes.width/this.sizes.height
this.instance.updateProjectionMatrix()
}
}
Similar to the camera we can create a class for the renderer
import * as THREE from 'three'
export default class Renderer {
constructor(){
this.experience = new Experience();
this.canvas = this.experience.canvas;
this.sizes = this.experience.sizes;
this.szene = this.experience.scene;
this.camera= this.experience.camera;
this.setRendererInstance()
}
setRendererInstance(){
this.instance = new THREE.WebGLRenderer({
canvas:this.canvas,
antialias:true
})
this.instance.toneMapping = THREE.CineonToneMapping
this.instance.toneMappingExposure = 1.75
this.instance.shadowMap.enabled = true
this.instance.shadowMap.type = THREE.PCFSoftShadowMap;
this.instance.setSize(this.sizes.width, this.sizes.height);
this.instance.setPixelRation(this.sizes.pixelRatio);
}
resize(){
this.instance.setSize(this.sizes.width,this.sizes.height);
this.instance.setPixelRatio(this.sizes.pixelRatio);
}
update(){
this.instance.render(this.scene,this.camera.camInstance);
}
}
import Renderer from '/Renderer.js'
export default class Experience{
constructor(canvas){
...
this.renderer = new Renderer()
}
resize(){
this.renderer.resize();
this.camera.resize();
}
update(){
this.camera.update()
this.renderer.update()
}
}
And collect then all elements in a World class
export default class World{
constructor(){
this.experience = new Experience();
this.scene = this.experience.scene;
}
}
For the world class we then can create classes like Environment with contain the lights, environmentmaps etc.
What can make the code more structured is also a ResourceLoader class dedicated to loading the models
import EventEmitter from '/EventEmitter.js'
import * as THREE from 'three'
import { GLTFLoader } from 'three/examples/jsm/loaders/GLTFLoader.js'
export default class ResourceLoader extends EventEmitter {
constructor(sources){
super()
this.sources = sources
this.items = {}
this.toLoad = this.sources.length;
this.loaded = 0;
this.setLoaders();
this.startLoading();
}
setLoaders(){
this.loaders = {}
this.loaders.gltfLoader = new GLTFLoader();
this.loaders.textureLoader = new THREE.TextureLoader();
this.loaders.cubeTextureLoader = new THREE.CubeTextureLoader();
}
startLoader(){
for(const src of this.sources){
if(src.type === 'gltfModel'){
this.loaders.gltfLoader.load(src.path,(file)=>{
console.log(file,src);
this.sourceLoaded(src,file);
})
} else if(src.type=== 'texture'){
this.loaders.textureLoader.load(
src.path,(file)=>{
console.log(file,src);
this.sourceLoaded(src,file);
}
)
} else if(src.type==='cubeTexture'){
this.loaders.cubeTextureLoader.load(
src.path,(file)=>{
console.log(file,src);
this.sourceLoaded(src,file);
}
)
}
}
}
sourceLoaded(src,file){
items[src.name] = file;
this.loaded++;
if(this.loaded === this.toLoad){
this.trigger('allItemsLoaded')
}
}
}
//sources.js
export default [
{
name:'asset1',
type:'cubeTexture',
path:[
'text/px.jpg',
'text/nx.jpg',
...
]
}
]
We then can listen to the allItemsLoaded event an execute further code
export default class World{
...
//wait till resources are loaded
this.resources.on('allItemsLoaded'), () => {
this.environment = new Environment()
}
}
It also can be useful to create a own class for the DebugUI
import GUI from 'lil-gui'
export default class Debug{
constructor(){
// this allows to only show the debug ui if acces the webisite with #debug at the end
//we check if debug is present with window.location.hash
this.active = window.location.hash === '#debug'
if(this.active){
this.ui = new GUI
}
}
}
It is also important that when the Three.js experience is not used any more or some objects get distroyed that need to properly clean up.
export default class Experience{
...
destroy(){
//sizes and till still gonna listen to the native JS events so we need to handle to stop listen to them as well
this.sizes.off('resize')
this.time.off('tick')
this.scene.traverse((child) => {
if(child instanceof THREE.Mesh){
child.geometry.dispose();
//Loop through material properties
for(const key in child.material){
const value = child.material[key]
if(value && typeof value.dispose === 'function')
{
value.dispose()
}
}
}
})
this.camera.instance.dispose()
this.renderer.instance.dispose()
if(this.debug.active){
this.debug.ui.destroy()
}
}
}
Own hacks
Tile effect
This often makes sense for big floor materials
const tex = textureLoader.load(...)
tex.repeat.set(2,2)
tex.wrapS = tex.wrapT = THREE.MirroredRepeatWrapping
//tex.wrapS = tex.wrapT = THREE.RepeatWrapping
